Product Information
The HPE DF300BB6C3 is a 300GB enterprise hard drive spinning at 15,000 RPM. It uses the 3.5 inch large form factor, a 3Gb SAS interface and a hot swap carrier, and is intended for HPE ProLiant Gen2 through Gen7 servers.
Key Features
- 300GB capacity at 15K RPM
- SAS 3Gb/s interface
- 3.5 inch LFF
- Hot swap, enterprise class
Condition: New Bulk Pack
Warranty: 90 Days Warranty
Specifications
Brand: HPE
MPN: DF300BB6C3
Option Part Number: 431944-B21
Spare Part Number: 432146-001
Model Number: DF300BB6C3
Assembly Number: 417190-004
General
Device Type: Hard Drive - Hot-Swap
HDD Capacity: 300GB
Form Factor: 3.5 Inch LFF
Interface: SAS-3Gbps
Spindle Speed: 15000 RPM
External Data Transfer Rate: 300 MBps
Enclosure: Hot Swap
Drive Technology (Fill): Air
Carrier Type: Standard Carrier
Workload: Enterprise
Bundled with: HPE Standard Drive Carrier
Performance
Drive Transfer Rate: 3 Gb/sec (external)
Spindle Speed: 15000 RPM
Seek Time: 3.6 ms (average) / 11 ms (max)
Track-to-Track Seek Time: 0.57 ms
Expansion & Connectivity
Interfaces: 1 x SAS 3 Gb/s
Compatible Bays: 3.5" LFF
Environmental Parameters
Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F
Compatible Systems
- HPE ProLiant DL Series: DL140 Gen3 (3.5 inch), DL145 Gen3 (3.5 inch), DL160 Gen5 (3.5 inch), DL160 Gen5p (3.5 inch), DL180 (3.5 inch), DL320 Gen4 (3.5 inch), DL320 Gen5 (3.5 inch), DL320 Gen5p (3.5 inch), DL320s (3.5 inch)
- HPE ProLiant ML Series: ML150 Gen3 (3.5 inch), ML150 Gen5 (3.5 inch), ML150 Gen5 Base (3.5 inch), ML150 Gen5 Performance (3.5 inch), ML310 Gen3 (3.5 inch), ML310 Gen4 (3.5 inch), ML310 Gen5 (3.5 inch), ML350 Gen5 1.5 TB Storage Server, ML350 Gen5 1.8TB SAS Storage Server, ML350 Gen5 3 TB Storage Server, ML350 Gen5 960 GB Storage Server
- HPE StorageWorks Modular Smart Array 60, 60 Starter Kit
Not sure this drive fits your system? Send us your server or storage array model and the DatorPro team will confirm compatibility before you order.
