Product Information
HPE's FlexFabric 5710 24XGT 6QSFP+ or 2QSFP28 (JL689A) is a top of rack data center switch with 24 1/10GBASE-T ports and uplinks configurable as six 40G QSFP+ or two 100G QSFP28. It offers 960 Gbps of capacity and a 12 MB packet buffer. Power supplies are not installed.
Key Features
- 24 x 1/10GBASE-T RJ-45 ports
- 6 x 40G QSFP+ or 2 x 100G QSFP28
- 960 Gbps, 714 Mpps
- 12 MB packet buffer, DCB
- Power supplies not installed, 1+1 supported
- Rack mount
Product Information
Brand: HPE
Manufacturer: Aruba
Product Line: HPE FlexFabric
Model: 5710 24XGT 6QSFP+ or 2QSFP28
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Black
Network and Communication
Advanced Switching: Layer 3
Switching Type: 10 Gigabit Ethernet
Manageable: Yes
Remote Management: CLI, SNMP 1, SNMP 2c, SNMP 3, SSH, SSH-2, TACACS+, Telnet, TFTP
Routing Protocol: BGP, BGP-4, Bidirectional Forwarding Detection (BFD), ECMP, IGMP, IGMPv2, IGMPv3, IS-IS, MPLS, OSPF, OSPFv2, OSPFv3, RIP, RIP-2, RIPng, Static IPv4 routing, Static IPv6 routing, VRRP
Authentication Method: RADIUS, Secure Shell (SSH), Secure Shell v.2 (SSH2), TACACS, TACACS+
Performance: Latency (10 Gbps): 2.5 µs, Routing/switching capacity: 960 Gbps, Throughput: 714 Mpps
Capacity: ARP entries: 68000, IPv4 routing table entries: 16000, IPv6 routing table entries: 8000, Static ARP entries: 1000, Virtual interfaces (VLANs): 4094
MAC Address Table Size: 208000 entries
Jumbo Frame Support: Yes
Features: 12MB packet buffer, 5 fan tray slots, Access Control List (ACL) support, ARP support, BOOTP support, Class of Service (CoS), Data Center Bridging (DCB), Data Center Bridging Exchange (DCBX) support, Device Link Detection Protocol (DLDP) support, DHCP relay, DHCP snooping, DHCP support, DiffServ Code Point (DSCP) support, DiffServ support, Equal-Cost Multipath (ECMP), FCoE forwarding, FCoE support, Flow control, IGMP snooping, Intelligent Resilient Framework Technology (IRF), IPv4 support, IPv6 support, Jumbo Frames support, LLDP support, Management Information Base (MIB), MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, NTP time synchronization, PIM snooping, Port mirroring, Port Security, Priority-based flow control, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Role based access control, sFlow, SNTP support, Spanning Tree Protocol (STP) support, Strict Priority (SP), Syslog support, Top-of-Rack (ToR), Tunneling, VLAN support, Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), Weighted Round Robin (WRR) queuing
Connectivity
Ports: 24
Port Quantity: 24
Port Type: 1 Gigabit / 10 Gigabit Ethernet
Ports (2nd) Quantity: 6
Ports Type (2nd): 40 Gigabit QSFP+
Interface Provided: 1 x 10/100/1000 Base-T management, 1 x console (mini-USB), 1 x management SFP, 1 x serial (console), 24 x Gigabit / 10Gbit LAN RJ-45
Power
Device Type: Internal power supply (not installed)
Power Supplies Supported: 2
Redundant Power Supply Supported: 1+1 (with optional power supply)
Redundant Power Supply: Optional
Hot-Plug: Hot-plug
Memory and Processor
RAM Installed: 4 GB
Memory Technology: SDRAM
Flash Memory Installed: 1 GB
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 113 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
MTBF: 43,12 Year
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Height (Rack Units): 1
Dimensions and Weight
Height: 1.7 inch
Width: 17.3 inch
Depth: 18.1 inch
Weight: 21.83 lbs
Certifications and Listing
Compliant Standards: ANATEL, AS/NZS 60950-1, AS/NZS CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, CISPR 24, CISPR 32 Class A, CNS 13438, CNS 14336-1, EN 55032 Class A, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN55024, ETSI EN 300 386, FCC CFR47 Part 15, FCC Class A certified, ICES-003 Class A, IEC 60950-1, KN32, KN35, RoHS, TCVN 7189, UL 60950-1, VCCI Class A
Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ag, IEEE 802.3ah, IEEE 802.3x
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Limited Warranty: 1 Year
Service & Support Details: Limited warranty - 1 year
