Product Information
The HPE FlexNetwork MSR958X is a fixed port branch router that combines routing, switching, wireless and security in one rack mountable unit. It runs Comware v7 and supports Zero Touch Provisioning, which makes it a practical choice for small branch offices on a corporate WAN.
Key Features
- 6 WAN ports: 2 x Gigabit Ethernet RJ-45 and 4 x Gigabit SFP
- Built in 8 port Gigabit switch for the LAN
- 802.11b/g/n wireless LAN
- Firewall, IPS and VPN support with AES encryption
- Marvell ARM64 processor at 1.6 GHz with 2 GB RAM and 4 GB flash
- 36 watt operating power draw
Specifications
General
Part Number: S0P11A#ABA
Brand: HPE
Manufacturer: Aruba
Product Line: HPE FlexNetwork
Model: MSR958X
Product Type: Router
Form Factor: Rack-mountable
Packaged Quantity: 1
Processor and Memory
Processor Brand: Marvell
Processor Number: ARM64
Processors Installed: 1
Clock Speed: 1.6 GHZ
RAM Installed: 2 GB
Flash Memory Installed: 4 GB
Networking
Connectivity Technology: Wired, Wireless
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wireless LAN: 802.11b/g/n
Integrated Switch: 8-port switch
WAN Ports Quantity: 6
Network Standard: AAL5, APPN, ARP, DHCP, FTP, ICMP/IP, IPSec, L2TP, NTP, PAP, RSVP, SFTP, TCP/IP, UDP/IP
Routing Protocol: BGP, BGP-4, BGP-4+, BGP+, Bidirectional PIM, CIDR, ECMP, EGP, GRE, IGMP, IGMPv2, IGMPv3, IS-IS, MPLS, MSDP, OSPF, OSPFv3, RIP, RIP-1, RIP-2, RIPng, Static IPv4 routing, Static IPv6 routing, URPF, VRRP
Networking Standards: IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.2, IEEE 802.3, IEEE 802.3ad (LACP)
Capacity: IPv4 forwarding table entries: 200000, IPv4 routing table entries: 200000, IPv6 forwarding table entries: 200000, IPv6 routing table entries: 200000, VPN tunnels: 100
Features: Access Control List (ACL) support, Class of Service (CoS), Committed Access Rate (CAR), DHCP relay, Dynamic Virtual Private Network (DVPN), Ethernet over IP (EtherIP), Group Domain Virtual Private Network (GDVPN), ICMP Router Discovery Protocol (IRDP), Intrusion Prevention System (IPS), Layer 2 switching, Layer 3 switching, Link Fragmentation and Interleaving (LFI), Loopback, Management Information Base (MIB), Management Information Base (MIB) II, Multicast Border Gateway Protocol (MBGP), Multiple Spanning Tree Protocol (MSTP) support, NAT support, Packet storm protection, Port isolation, Port mirroring, Quality of Service (QoS), Random early detection (RED), Rapid Spanning Tree Protocol (RSTP) support, sFlow, Source-Specific Multicast (SSM), Spanning Tree Protocol (STP) support, Traffic shaping, Tunneling, Type of Service (ToS), Unicast Reverse Path Forwarding (URPF), VLAN support, VPN support, Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED)
Highlights: Firewall, USB port, VPN support
Remote Management: CLI, HTTP, RMON, SNMP 1, SNMP 2, SNMP 3, Telnet, TFTP
Status Indicators: SD card, System, VPN
Ports and Expansion
Interface Provided: 1 x console - RJ-45, 1 x USB 2.0, LAN: 8 x Ethernet 1000 - RJ-45, WAN: 2 x Ethernet 1000 - RJ-45, WAN: 4 x Ethernet 1000 - SFP (mini-GBIC)
Security
Encryption: 128-bit AES, 192-bit AES, 256-bit AES, AES, DES, MD5, SHA-1, TLS, Triple DES
Authentication Method: CHAP, PAP, RADIUS, Secure Shell (SSH), Secure Shell v.2 (SSH2), TACACS+
Power
Required Voltage: AC 100-240 volt
Power Consumption Operational: 36 watt
Power Device: Internal power supply
Operating Environment
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 113 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Size and Weight
Weight: 2.65 lbs
Color Category: Gray, White
Certifications
Compliant Standards: ANSI C63.4, AS/NZS 60950, AS/NZS CISPR 22 Class B, CAN/CSA C22.2 No. 60950-1-03, CAN/CSA-C22.2 No. 60950-1, EMC 2004/108/EC, EN 300 386 V1.3.3, EN 60825-1, EN 60825-2, EN 60950-1, EN 61000-3-2:2006, EN 61000-3-3:1995+A1:2001+A2:2005, EN 61000-4-11:2004, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN55022, EN55024:1998+A1:2001+A2:2003, ETSI, FCC CFR47 Part 15 B, FCC Part 68 / CS03 Issue 8, FDA, ICES-003 Class B, IEC 60950-1, RoHS, UL 60950-1, WEEE, X.509
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Other
Region: United States
Localization: English
