Product Information
The HPE 376160-B21 is a dual port 10Gb InfiniBand adapter for HPE ProLiant servers. It is a plug-in card with two microGiGaCN ports and a PCI Express x8 host interface.
Key Features
- Mellanox InfiniRISC III processor
- Half and full duplex
Condition: Brand New in Factory Sealed Box
Warranty: Up to a 3-Years Manufacturer Warranty and a 30 Days Return Window through us
Part Numbers
Manufacturer: HPE
MPN: 376160-B21
Option Part Number: 376160-B21
Spare Part Number: 374931-001
General
Product Type: Network adapter - 2 ports
Form Factor: Plug-in card
Adapter Details
Bus Type: PCI Express x8
PCI Spec Revision: PCI-X 1.0a
Bus Voltage: 3.3 V
Connectivity: Wired
Data Link Protocol: InfiniBand
Transfer Rate: 10 Gbps
Features: Half duplex mode, full duplex mode
Processor: 1 x Mellanox InfiniRISC III
RAM: 128 MB
Connections
Cabling: 4x InfiniBand (SFF-8470)
Ports: 2 x network - microGiGaCN
Slot: 1 x PCI Express x8
Software and Compatibility
Supported Operating Systems: SuSE Linux Enterprise Server 8, Red Hat Enterprise Linux 2.1, Red Hat Enterprise Linux 3
Size and Weight
Width: 2.50 inch
Depth: 6.60 inch
Power and Environment
Compliance: FCC Class B certified, CISPR 22 Class B, EN 60950, IEC 60950, UL 60950, CSA 22.2 No. 60950
Operating Temp (Min): 32 °F
Operating Temp (Max): 131 °F
Operating Humidity: 0 - 85%
Compatible Systems
- HPE ProLiant DL Series: DL140 Gen2, DL145 Gen2, DL320 Gen3, DL360 Gen4, DL360 Gen4p, DL380 Gen4, DL380 Gen4 High Performance, DL385, DL580 Gen3, DL585
Not sure this adapter fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
