Product Information
The HPE 656089-001 is the InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544QSFP adapter for HPE ProLiant Gen8 servers, with two QSFP ports.
Key Features
- Built on Mellanox adapter technology
- Each port can run FDR InfiniBand or Ethernet, or the card can mix both
- Built for HPC clusters and clustered server and storage work that need low latency
- Offload engines keep CPU overhead low and raise throughput
- RoCE brings efficient, low latency RDMA to both Layer 2 and Layer 3 networks
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: 656089-001
Option Part Number: 649281-B21
Spare Part Number: 656089-001
General
Product Type: Network Adapter - InfiniBand
Adapter Details
Connectivity: Wired
Interface Type: PCIe 3.0 X8
Data Link Protocol: 10 Gigabit Ethernet, 40 Gigabit Ethernet, InfiniBand
Transfer Rate: 56 Gbps
Features: InfiniBand FDR Link support
Connections
Ports: Two QSFP Ports, 2 x 40Gb Ethernet / InfiniBand FDR - QSFP Operating Temperature
Power and Environment
Operating Temp (Max): 131 °F
Operating Temp (Min): 32 °F
Compatible Systems
- HPE ProLiant DL Series: DL360p Gen8, DL380p Gen8, DL385 Gen8
Not sure this adapter fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
