Product Information
Add 1 TB of midline storage to HPE ProLiant Gen4 through Gen7 servers with the HPE MB1000FCWPP. This 3.5 inch LFF (large form factor) drive runs at 7,200 RPM over a dual port SAS 6Gb/s connection.
It suits capacity driven jobs such as bulk storage, expanding digital content libraries, and cloud or web infrastructure.
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: MB1000FCWPP
Option Part Number: 507614-B21
Spare Part Number: 508011-001
Model Number: MB1000FCWPP
Assembly Number: 693672-004
Drive Details
Drive Type: Hard Drive - Hot-Swap
Storage Capacity: 1 TB
Form Factor: 3.5 inch LFF
Host Interface: SAS-6Gbps
Enclosure: Hot Pluggable
Sector Size (Bytes): 512
Internal Fill: Air
Carrier: Standard Carrier
Workload Class: Midline
Features: Dual Port
Ships With: HPE Standard Carrier
Performance
External Transfer Rate: 6 Gb/sec
Rotational Speed: 7200 RPM
Average Seek: 8.5 ms
Maximum Seek: 16.20 ms
Track-to-Track Seek: 0.5 ms
Connections
Ports: 1 x SAS 6 Gb/s
Fits Bay: 3.5" LFF
Operating Environment
Operating Temp (Min): 50 °F
Operating Temp (Max): 95 °F
Compatible Systems
- HPE ProLiant DL Series: DL1000 DL120 (Gen5 Gen6 Gen7) DL140 (Gen3) DL145 (Gen3) DL160 (Gen5 Gen5p Gen6 Gen7) DL160se (Gen6 Gen7) DL165 (Gen5 Gen5p Gen6 Gen7) DL170e (Gen6) DL170h (Gen6) DL2x170h (Gen6) DL4x170h (Gen6) DL180 (Gen5 Gen6 Gen7) DL185 (Gen5) DL320 (Gen3 Gen4 Gen5 Gen5p Gen6 Gen7) DL320sDL370 (Gen6 Gen7) DL380 (Gen4 Gen5 Gen6 Gen7) DL385 (Gen5 Gen5p Gen6 Gen7) DL580 (Gen4 Gen5 Gen6 Gen7) DL585 (Gen2 Gen5 Gen6 Gen7) DL785 (Gen5 Gen6)
- HPE ProLiant ML Series: ML110 (Gen7) ML150 (Gen5 Gen6 Gen7) ML310 (Gen5p) ML330 (Gen6) ML350 (Gen5 Gen6 Gen7) ML370 (Gen5 Gen6 Gen7)
- HPE Storage Arrays: D2600 MDS600 MSA60 60 Modular Array StoreAll 9730
- HPE StoreEasy: 1430 1440 1530 1540 1630 1640 1830 1840 5530 X1400 X1500 X1600 X1800 X3400 X3800
- HPE StoreVirtual: P4000 P4100 P4300 (Gen2) P4500 (Gen2)
Not sure this drive fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
