Product Information
HPE MB4000FCWDK 4TB Midline Hard Drive for ProLiant Gen2 to Gen7 Servers. This 3.5 inch Large Form Factor (LFF) drive spins at 7,200 RPM and connects through a dual port SAS 6Gbps interface.
Condition: New Bulk Pack
Warranty: 90 Days Warranty
Midline drives put capacity first. Running at 7,200 RPM, this drive offers a lower cost per gigabyte than 10K and 15K enterprise drives, so it fits well where you need plenty of space for file shares, backups, archives, video and other bulk data.
The SAS 6Gbps interface gives this drive a reliable, server grade connection. SAS drives can be swapped while the system is running and are designed for nonstop duty in rack servers and storage arrays.
Part Numbers
Brand: HPE
MPN: MB4000FCWDK
Option Part Number: 693689-B21
Spare Part Number: 693721-001
Model Number: MB4000FCWDK
Assembly Number: 695507-004
Assembly Number: 695507-008
HPE GPN: 652755-007
Drive Details
Device Type: Hard Drive - Hot-Swap
Capacity: 4 TB
Interface: SAS 6Gbps
Form Factor: 3.5 inch LFF
Bytes per Sector: 512
Drive Technology (Fill): Air
Plug Type: Hot Pluggable
Carrier Type: Standard Carrier
Workload Type: Midline
Features: Dual Port
Bundled with: HPE Standard Carrier
Speed and Throughput
Drive Transfer Rate: 6 Gb/sec (external)
Spindle Speed: 7200 RPM
Average Seek Time: 8.5 ms
Max Seek Time: 15.7 ms
Track-to-Track Seek Time: 0.7 ms
Connection
Compatible Bays: 1 x Hot-Swap - 3.5" LFF
Interfaces: 1 x SAS 6Gb/s
Operating Environment
Max Operating Temperature: 35 °C
Min Operating Temperature: 10 °C
Size
Height: 2.64 cm
Width: 11.07 cm
Depth: 18.87 cm
Compatible Systems
HPE ProLiant DL Series: DL1000 DL120 (Gen5 Gen6 Gen7), DL140 (Gen3), DL145 (Gen3), DL160 (Gen5 Gen5p Gen6 Gen7), DL160se (Gen6 Gen7), DL165 (Gen5 Gen5p Gen6 Gen7), DL170e (Gen6), DL170h (Gen6), DL2x170h (Gen6), DL4x170h (Gen6), DL180 (Gen5 Gen6 Gen7), DL185 (Gen5), DL320 (Gen3 Gen4 Gen5 Gen5p Gen6 Gen7), DL320sDL370 (Gen6 Gen7), DL380 (Gen4 Gen5 Gen6 Gen7), DL385 (Gen5 Gen5p Gen6 Gen7), DL580 (Gen4 Gen5 Gen6 Gen7), DL585 (Gen2 Gen5 Gen6 Gen7), DL785 (Gen5 Gen6)
HPE ProLiant ML Series: ML110 (Gen7), ML150 (Gen5 Gen6 Gen7), ML310 (Gen5p), ML330 (Gen6), ML350 (Gen5 Gen6 Gen7), ML370 (Gen5 Gen6 Gen7)
HPE Storage Arrays: D2600 MDS600 MSA60 P4300 P4500 P4000 (Gen2), 60 Modular Array StoreAll 9730
HPE StoreEasy: 1430 1440 1530 1540 1630 1640 1830 1840 5530 X1400 X1500 X1600 X1800 X3400 X3800
HPE Modular Disk System 600
HPE StoreEasy 12 LFF Disk Enclosure
Not sure this drive fits your system? Send us your server or storage model and we will confirm compatibility before you order.
