Product Information
The HPE 313585-001 is the NC6170, a dual port 1000Base-SX fiber Gigabit Ethernet adapter on a hot plug PCI-X 133 MHz card, for HPE ProLiant servers.
Key Features
- Intel 82546EB controller
- Two LC fiber ports
- Full duplex, hot swap module replacement and load balancing
Condition: New Bulk Pack
Warranty: 90 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: 313585-001
Option Part Number: 313879-B21
Spare Part Number: 313585-001
Assembly Number: 313560-013
General
Product Type: Network adapter
Form Factor: Plug-in card
Adapter Details
Bus Type: PCI-X hot-plug 133 MHz
Connectivity: Wired
Data Link Protocol: GigE
Transfer Rate: 1 Gbps
Network/Transport Protocol: TCP/IP
Remote Management: SNMP
Status Indicators: Link activity
Features: Full duplex capability, hot swap module replacement, load balancing
Processor: 1 x 82546EB - Intel
RAM: 128 KB
Connections
Network Ports: 1000Base-SX x 2
Cabling: Ethernet 1000Base-SX
Max Transfer Distance: 1800 ft
Ports: 2 x 1000Base-SX - LC
Slot: 1 x PCI-X hot-plug 133 MHz
Software and Compatibility
Supported Operating Systems: Microsoft DOS, SCO OpenServer 5, Novell NetWare 4.x, Microsoft Windows 2000, Novell NetWare 5.x, Red Hat Linux, SuSe Linux, Novell NetWare 6.x, Caldera OpenUnix 8, Microsoft Windows Server 2003
Size and Weight
Depth: 6.50 inch
Height: 2.50 inch
Power and Environment
Compliance: IEEE 802.3z, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), FCC Class B certified, UL, CISPR 22 Class A, VCCI Class B ITE, BSMI CNS 13438 Class A, cUL, EN 60950, EN55022, ICES-003, EN55024
Operating Temp (Min): 32 °F
Operating Temp (Max): 131 °F
Operating Humidity: 10 - 95%
Compatible Systems
- HPE Compaq ProLiant DL Series: Compaq ProLiant DL320 Gen2, DL740, DL760 Gen2
- HPE NetServer LC2000
- HPE High Performance Cluster LC Series
- HPE NetServer LC2000, LC2000 Cluster
- HPE ProLiant DL Series: DL140 Gen2, DL145, DL145 Gen2, DL320 Gen2, DL320 Gen3, DL360 Gen3, DL360 Gen3 F200 Non-Integrated Cluster Bundle, DL360 Gen4, DL360 Gen4p, DL380 Gen3, DL380 Gen3 F200 Non-Integrated Cluster Bundle, DL380 Gen3 LifeKeeper for Linux Cluster Solution for Oracle, DL380 Gen3 LifeKeeper for Linux Cluster Solution for SAP, DL380 Gen3 LifeKeeper for Linux Cluster Solution for Sendmail, DL380 Gen3 Packaged Cluster, DL380 Gen4 High Performance, DL385, DL560, DL580 Gen2, DL580 Gen2 F100 Integrated Cluster Solution, DL580 Gen2 F200 Integrated Cluster Solution, DL580 Gen2 F200 Non-Integrated Cluster Bundle, DL585, DL740, DL760 Gen2
- HPE ProLiant ML Series: ML310 Gen2, ML330 Gen3, ML350 Gen3, ML350 Gen4, ML350 Gen4p, ML350 Gen4p Storage Server 1TB SATA Model, ML370 Gen3, ML370 Gen3 High Performance, ML370 Gen4, ML370 Gen4 High Performance, ML530 Gen2, ML570 Gen2
- HPE StorageWorks NAS 2000s External Storage, 2000s Internal Storage, 4000s, 9000s
Not sure this adapter fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
