Product Information
The HPE P07932-B21 is a 1.92TB mixed use solid state drive in the 3.5 inch large form factor (LFF) with a 6Gb SATA interface. The drive runs HPE digitally signed firmware. It comes in an HPE Smart Carrier Converter (SCC) for 3.5 inch bays. It is intended for HPE ProLiant Gen9 and Gen10 servers.
Key Features
- 1.92TB capacity
- SATA 6Gb/s interface
- 3.5 inch LFF
- Mixed Use workload
- Digitally signed firmware
- HPE Smart Carrier Converter (SCC)
Condition: Brand New in Factory Sealed Box
Warranty: Up to a 3-Years Manufacturer Warranty and a 30 Days Return Window through us
Specifications
Brand: HPE
MPN: P07932-B21
Option Part Number: P07932-B21
Spare Part Number: P08695-001
Model Number: MK001920GWUGK
Assembly Number: P07444-003
General
Device Type: Solid State Drive - Hot-Swap
Capacity: 1.92 TB
Form Factor: 3.5 inch LFF
Interface: SATA 6Gbps
NAND Flash Memory Type: Triple-level cell (TLC)
Connectivity: Single Port
Plug Type: Hot Pluggable
Carrier Type: Smart Carrier Converter (SCC)
Workload Type: Mixed Use
Bundled with: HPE Smart Carrier Converter (SCC)
Features: Digitally Signed Firmware (DS)
Platform Supported: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
Height: 7.00 mm (0.3 inch) Performance 30 Days Writes: 17500
Endurance DWPD (Drive Writes Per Day): 5
Drive Transfer Rate (External): 6 Gb/sec
Random Read IOPS (4KiB, Q=16): 59000
Max Random Read IOPS (4KiB): 62000@Q32
Random Write IOPS (4KiB, Q=16): 52500
Max Random Write IOPS (4KiB): 52000@Q16
MAX Seq Reads Throughput (MiB/s): 520
Max Seq Writes Throughput (MiB/s): 495
Random Read Avg. Latency uSec (4KiB,Q1): 125
Random Write Avg. Latency uSec (4KiB,Q1): 36
Expansion & Connectivity
Interfaces: 1 x SATA 6Gb/s
Compatible Bay: 3.5" LFF Power Consumption Idle Time: 1.50 Watt
Random Read: 3.10 Watt
Random Write: 3.10 Watt
Sequential Read: 5.40 Watt
Sequential Write: 6.80 Watt
Random Read/Write: 3.10 Watt
Maximum: 6.80 Watt
Product Dimensions & Weight
Height: 5.63 inch (14.30 cm)
Width: 5.75 inch (14.61 cm)
Depth: 10.00 inch (25.4 cm)
Weight: 3 lbs (1.36 kg)
Compatible Systems
- HPE ProLiant DL Series: DL360 Gen10 Server for CTERA (3.5 inch), DL360 Gen9 (3.5 inch), DL360 Gen9 Base (3.5 inch), DL360 Gen9 CMS (3.5 inch), DL360 Gen9 Entry (3.5 inch), DL360 Gen9 Performance (3.5 inch), DL360 Gen9 Special Server (3.5 inch), DL380 Gen9 (3.5 inch), DL380 Gen9 Base (3.5 inch), DL380 Gen9 Entry (3.5 inch), DL380 Gen9 High Performance (3.5 inch), DL380 Gen9 Performance (3.5 inch), DL380 Gen9 Scale-up SAP HANA Tailored Datacenter Integration Compute Block (3.5 inch), DL380 Gen9 Special (3.5 inch)
Not sure this drive fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
