Product Information
The HPE P10450-K21 is a 960GB mixed use solid state drive in the 3.5 inch large form factor (LFF) with a 12Gb SAS interface. The drive belongs to the HPE Value SAS line, uses TLC NAND and runs HPE digitally signed firmware. It comes in an HPE Smart Carrier Converter (SCC) for 3.5 inch bays. It is intended for HPE ProLiant Gen10 servers.
Key Features
- 960GB capacity
- SAS 12Gb/s interface
- 3.5 inch LFF
- Mixed Use workload
- Value SAS
- TLC NAND
- Digitally signed firmware
- HPE Smart Carrier Converter (SCC)
Condition: Brand New in Factory Sealed Box
Warranty: Up to a 3-Years Manufacturer Warranty and a 30 Days Return Window through us
Specifications
Brand: HPE
MPN: P10450-K21
Option Part Number: P10450-K21
Spare Part Number: P10605-001
General
Device Type: Solid State Drive - Hot-Swap
Capacity: 960 GB
Form Factor: 3.5 inch LFF
Interface: SAS 12Gbps
NAND Flash Memory
Type: Triple-level cell (TLC)
Plug Type: Hot Pluggable
Carrier Type: Smart Carrier Converter (SCC)
Workload Type: Mixed Use
Bundled with: HPE Smart Carrier Converter
Features: Digitally Signed Firmware, HPE Value SAS
Height: 15.00 mm(0.60 inch) Performance 30 Days Writes: 5250
Endurance DWPD (Drive Writes Per Day): 3
Random Read IOPS (4KiB, Q=16): 108000 IOPS
Max Random Read IOPS (4KiB): 155000@Q32
Random Write IOPS (4KiB, Q=16): 47000 IOPS
Max Random Write IOPS (4KiB): 48,000@Q4
Drive Transfer Rate: 12 Gb/sec (external)
Internal Data Rate (Read): 790 MBps
Internal Data Rate (Write): 635 MBps
Expansion & Connectivity
Compatible Bay: 3.5" LFF
Interfaces: 1 x SAS 12 Gb/s Power Consumption Idle Time: 4.26 Watt
Random Read: 4.97 Watt
Random Write: 4.97 Watt
Sequential Read: 6.71 Watt
Sequential Write: 6.95 Watt
Random Read/Write: 6.95 Watt
Maximum: 9.65 Watt
Minimum Dimensions & Weight
Height: 5.74 inch (14.58 cm)
Width: 10.00 inch (25.40 cm)
Depth: 8.63 inch (21.92 cm)
Weight: 3.00 lbs (1.36 kg)
Miscellaneous
Compliant Standards: WEEE
Compatible Systems
- HPE ProLiant DL Series:
- HPE ProLiant DL360 Gen10 (3.5 inch), DL360 Gen10 Base (3.5 inch), DL360 Gen10 Entry (3.5 inch), DL360 Gen10 High Performance (3.5 inch), DL360 Gen10 Low (3.5 inch), DL360 Gen10 Performance (3.5 inch), DL360 Gen10 SMB (3.5 inch), DL360 Gen10 Solution (3.5 inch), DL380 Gen10 (3.5 inch), DL380 Gen10 Base (3.5 inch), DL380 Gen10 Entry (3.5 inch), DL380 Gen10 Entry SMB (3.5 inch), DL380 Gen10 for Cohesity DataPlatform (3.5 inch), DL380 Gen10 High Performance (3.5 inch), DL380 Gen10 Network Choice (3.5 inch), DL380 Gen10 Performance (3.5 inch), DL380 Gen10 SMB (3.5 inch), DL380 Gen10 Solution (3.5 inch), DL380 Gen9 (3.5 inch), DL380 Gen9 Base (3.5 inch), DL380 Gen9 Entry (3.5 inch), DL380 Gen9 High Performance (3.5 inch), DL380 Gen9 Performance (3.5 inch), DL380 Gen9 Scale-up SAP HANA Tailored Datacenter Integration Compute Block (3.5 inch), DL380 Gen9 Special (3.5 inch), DL385 Gen10 (3.5 inch), DL385 Gen10 Base (3.5 inch), DL385 Gen10 Entry (3.5 inch), DL385 Gen10 High-Perferformance (3.5 inch), DL385 Gen10 High-Performance (3.5 inch), DL385 Gen10 Performance (3.5 inch), DL385 Gen10 Solution (3.5 inch)
Not sure this drive fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
