Product Information
The HPE P29161-X21 is a 960GB read intensive solid state drive in the 2.5 inch small form factor (SFF) with an NVMe U.3 PCIe interface. The drive sits in the HPE Mainstream Performance class and runs HPE digitally signed firmware. It ships in an HPE Basic Carrier (BC). It is intended for HPE ProLiant Gen10 Plus servers.
Key Features
- 960GB capacity
- NVMe U.3 PCIe
- 2.5 inch SFF
- Read Intensive workload
- Mainstream Performance
- Digitally signed firmware
- Basic Carrier (BC)
Condition: New Bulk Pack
Warranty: 90 Days Warranty
Specifications
Brand: HPE
MPN: P29161-X21
Option Part Number: P29161-X21
Spare Part Number: P41487-001
General
Device Type: Solid State Drive - Hot-Swap
Capacity: 960 GB
Form Factor: 2.5 inch SFF
Interface: PCI Express 3.0 x4 (NVMe)
Plug Type: Hot Pluggable
Carrier Type: Basic Carrier (BC)
Workload Type: Read Intensive
NAND Flash Memory
Type: Triple-Level Cell (TLC)
Connectivity: Single Port
Bundled with: HPE Basic Carrier (SBC)
Features: Digitally Signed Firmware (DS)
Platform Supported: HPE ProLiant Rack
Height: 15.00 mm (0.60 inch) Performance 30 Days Writes: 2691
Endurance DWPD (Drive Writes Per Day): 1.50
MAX Seq Reads Throughput (MiB/s): 5900
Max Seq Writes Throughput (MiB/s): 1400
Random Read Avg. Latency uSec (4KiB,Q1): 79
Random Write Avg. Latency uSec (4KiB,Q1): 28
Random Read IOPS (4KiB, Q=16): 190000
Random Write IOPS (4KiB, Q=16): 69000
Max Random Read IOPS (4KiB): 520000@Q256
Max Random Write IOPS (4KiB): 69000@Q256
Expansion & Connectivity
Interfaces: 1 x PCI Express 3.0 x4 (NVMe)
Compatible Bay: 2.5" SFF Power Consumption Idle Time: 4.40 Watt
Random Read: 7.25 Watt
Random Write: 7.95 Watt
Sequential Read: 9.51 Watt
Sequential Write: 7.81 Watt
Random Read/Write: 7.27 Watt
Maximum: 9.51 Watt
Compatible Systems
- HPE ProLiant DL Series: DL325 Gen10 Plus V2 (2.5inch), DL325 Gen10 Plus V2 Base (2.5inch), DL325 Gen10 Plus V2 for Weka Base Tracking (2.5inch), DL325 Gen10 Plus V2 Performance (2.5inch), DL345 Gen10 Plus (2.5inch), DL345 Gen10 Plus Base (2.5inch), DL345 Gen10 Plus Entry (2.5inch), DL360 Gen10 Plus (2.5inch), DL360 Gen10 Plus All-NVMe Server for Software Defined Storage (2.5inch), DL360 Gen10 Plus for Weka Base Tracking (2.5inch), DL360 Gen10 Plus Network Choice (2.5inch), DL365 Gen10 Plus (2.5inch), DL380 Gen10 Plus (2.5inch), DL380 Gen10 Plus Network Choice (2.5inch), DL385 Gen10 Plus V2 (2.5inch), DL385 Gen10 Plus V2 Base (2.5inch), DL385 Gen10 Plus V2 Entry (2.5inch)
- HPE SimpliVity 325 Gen10 Plus V2 Node (2.5inch)
Not sure this SSD fits your server? Send us your server model and the DatorPro team will confirm compatibility before you order.
