Product Information
The HPE P40497-B21 gives you 480GB of read intensive flash storage in a 2.5 inch small form factor (SFF) SSD with a 6Gb SATA interface. The drive runs HPE digitally signed firmware. It comes in an HPE Basic Carrier (BC). It is intended for HPE ProLiant Gen10 Plus servers.
Key Features
- 480GB capacity
- SATA 6Gb/s interface
- 2.5 inch SFF
- Read Intensive workload
- Digitally signed firmware
- HPE Basic Carrier (BC)
Condition: New Bulk Pack
Warranty: 90 Days Warranty
Specifications
Brand: HPE
MPN: P40497-B21
Option Part Number: P40497-B21
Spare Part Number: P41522-001
General
Device Type: Solid State Drive - Hot-Swap
Capacity: 480GB
Form Factor: 2.5 inch SFF
Interface: SATA 6Gbps
NAND Flash Memory Type: Triple-level cell (TLC)
Plug Type: Hot Pluggable
Connectivity
Type: Single
Carrier Type: Basic Carrier (BC)
Workload Type: Read Intensive
Bundled with: HPE Basic Carrier (BC)
Features: Digitally Signed Firmware (DS)
Platform Supported: HPE Mainstream Compute Platforms
Height: 7.00 mm(0.30 inch) Performance 30 Days Writes (TB): 430
Endurance DWPD (Drive Writes Per Day): 0.50
Drive Transfer Rate: 6 Gbps (external)
MAX Seq. Reads Throughput (MiB/s): 510
MAX Seq. Writes Throughput (MiB/s): 300
Random Read Average Latency uSec (4KiB,Q1): 125
Random Write Average Latency uSec (4KiB,Q1): 75
Random Read IOPS (4KiB, Q=16): 63000
Random Write IOPS (4KiB, Q=16): 15000
MAX Random Read IOPS (4KiB): 65500@Q32
MAX Random Write IOPS (4KiB): 15400@Q1
Expansion & Connectivity
Interfaces: 1 x SATA 6 Gb/s
Compatible Bay: 2.5" SFF Power Consumption Idle Time: 1.27 Watt
Random Read: 2.92 Watt
Random Write: 2.92 Watt
Sequential Read: 3.06 Watt
Sequential Write: 3.36 Watt
Random Read/Write: 2.92 Watt
MAX: 3.36 Watt
Product Dimensions & Weight
Height: 5.75 (14.61 cm)
Width: 8.63 inch (21.92 cm)
Depth: 9.00 inch (22.86 cm)
Weight: 1.10 lbs (0.50 kg)
Compatible Systems
- HPE ProLiant Generation8 Generation9 Generation10 Servers
Not sure this drive fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
