Product Information
The HPE P40503-B21 is a 960GB mixed use solid state drive in the 2.5 inch small form factor (SFF) with a 6Gb SATA interface. The drive runs HPE digitally signed firmware. It comes in an HPE Basic Carrier (BC). It is intended for HPE ProLiant Gen10 Plus servers.
Key Features
- 960GB capacity
- SATA 6Gb/s interface
- 2.5 inch SFF
- Mixed Use workload
- Digitally signed firmware
- HPE Basic Carrier (BC)
Condition: New Bulk Pack
Warranty: 90 Days Warranty
Specifications
Brand: HPE
MPN: P40503-B21
Option Part Number: P40503-B21
Spare Part Number: P41528-001
General
Device Type: Solid State Drive - Hot-Swap
Capacity: 960 GB
Form Factor: 2.5 inch SFF
Interface: SATA 6Gbps
NAND Flash Memory Type: Triple-level cell (TLC)
Plug Type: Hot Pluggable
Connectivity
Type: Single Port
Carrier Type: Basic Carrier (BC)
Workload Type: Mixed Use
Bundled with: HPE Basic Carrier (BC)
Features: Digitally Signed Firmware (DS)
Platform Supported: Mainstream Compute Platforms
Height: 7.00 mm Performance 30 Days Writes (TB): 6000
Endurance DWPD (Drive Writes Per Day): 3.40
Drive Transfer Rate: 6 Gbps (external)
MAX Seq. Reads Throughput (MiB/s): 520
MAX Seq. Writes Throughput (MiB/s): 480
Random Read Average Latency uSec (4KiB,Q1): 125
Random Write Average Latency uSec (4KiB,Q1): 50
Random Read IOPS (4KiB, Q=16): 61000
Random Write IOPS (4KiB, Q=16): 31000
MAX Random Read IOPS (4KiB): 72000@Q32
MAX Random Write IOPS (4KiB): 31000@Q4
Expansion & Connectivity
Interfaces: 1 x SATA 6 Gb/s
Compatible Bay: 2.5" SFF Power Consumption Idle Time: 1.37 Watt
Random Read: 2.81 Watt
Random Write: 2.81 Watt
Sequential Read: 3.09 Watt
Sequential Write: 3.93 Watt
Random Read/Write: 2.81 Watt
MAX: 3.93 Watt
Product Dimensions & Weight
Height: 5.50 inch (13.97 cm)
Width: 5.75 inch (14.61 cm)
Depth: 8.75 inch (22.23 cm)
Weight: 1.10 lbs (0.50 kg)
Compatible Systems
- HPE ProLiant DL Series: DL20 Gen10 Plus (2.5inch), DL20 Gen10 Plus Base (2.5inch), DL20 Gen10 Plus Entry (2.5inch), DL20 Gen10 Plus High Performance (2.5inch), DL20 Gen10 Plus Performance (2.5inch), DL325 Gen10 Plus V2 (2.5inch), DL325 Gen10 Plus V2 Base (2.5inch), DL325 Gen10 Plus V2 for Weka Base Tracking (2.5inch), DL325 Gen10 Plus V2 Performance (2.5inch), DL345 Gen10 Plus (2.5inch), DL345 Gen10 Plus Base (2.5inch), DL345 Gen10 Plus Entry (2.5inch), DL360 Gen10 Plus (2.5inch), DL360 Gen10 Plus All-NVMe Server for Software Defined Storage (2.5inch), DL360 Gen10 Plus for Weka Base Tracking (2.5inch), DL360 Gen10 Plus Network Choice (2.5inch), DL365 Gen10 Plus (2.5inch), DL380 Gen10 Plus (2.5inch), DL380 Gen10 Plus Network Choice (2.5inch)
- HPE ProLiant ML Series: ML30 Gen10 Plus (2.5inch), ML30 Gen10 Plus Entry (2.5inch), ML30 Gen10 Plus Performance (2.5inch)
- HPE SimpliVity 325 Gen10 Plus V2 Node (2.5inch)
Not sure this drive fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
