Product Information
The HPE 827605-001 is the StoreFabric CN1100R, a converged network adapter (CNA) with two 10GBASE-T ports for HPE ProLiant Gen10 servers. It carries Ethernet, iSCSI and Fibre Channel over 10GbE on a PCIe 2.0 x8 card, using FCoE and CEE standards.
Key Features
- Ethernet, iSCSI and Fibre Channel over one converged adapter using FCoE and CEE
- Fewer adapters and cables, with lower power, cooling and running costs
- Keeps your existing Ethernet and Fibre Channel setup in place
- HPE tested it with ProLiant servers and its own top of rack (ToR) switches
- Ships with both half height and full height brackets
Also Supported
Converged Infrastructure, Flexible Connect, 10G BASE-T, Jumbo Frames, DPDK, TCP/IP stateless offloads, Tunnel offload (VXLAN, NVGRE), MSI and MSI-X, TOE, VMware NetQueue and Microsoft VMQ virtualization support, Checksum and segmentation offload, IPv6, RSS, Precision Time Protocol (PTP), NIC teaming, Network Partitioning (NPAR)
Condition: Brand New in Factory Sealed Box
Warranty: Up to a 3-Years Manufacturer Warranty and a 30 Days Return Window through us
Part Numbers
Manufacturer: HPE
Part Number: 827605-001
Option Part Number: N3U52A
Spare Part Number: 827605-001
General
Product Type: Network Adapter - with Both Brackets (Half-Height Bracket and Full-Height Bracket)
Generation: CN1100R
Form Factor: Plug-in Card - Low Profile
Adapter Details
Bus Type: PCI Express 2.0 x8
Connectivity: Wired
Data Link Protocol: 10 GigE, FCoE, 10Gb CEE
Transfer Rate: 10 Gbps
Network/Transport Protocol: iSCSI
Connections
In the Box: Half-Height (Low-Profile) Bracket and Full-Height Bracket
Cabling: Ethernet 10GBase-T
Ports: 10Gb Ethernet x 2, 2 x 10GBase-T
Software and Compatibility
Supported Operating Systems: SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux
Size and Weight
Height: 7.16 inch (18.2 cm)
Width: 4.72 inch (12 cm)
Depth: 0.86 inch (2.18 cm)
Weight: 1 lbs
Power and Environment
Compliance: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau
Operating Humidity: 15 - 80% (non-condensing)
Operating Temp (Max): 45 °C
Operating Temp (Min): 0 °C
Compatible Systems
- HPE ProLiant XL Series: XL170r Gen10, XL190r Gen10 Servers
- HPE StoreEasy 3850 Gateway Single Node
Not sure this adapter fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
