Product Information
The HPE 827607-001 StoreFabric CN1200E is a converged network adapter (CNA) with two 10GBASE-T ports. It carries Ethernet, iSCSI and Fibre Channel over 10GbE on a PCIe 3.0 x8 card, using FCoE and CEE standards.
Key Features
- Ethernet, iSCSI and Fibre Channel over one converged adapter using FCoE and CEE
- Fewer adapters and cables, with lower power, cooling and running costs
- Keeps your existing Ethernet and Fibre Channel setup in place
- HPE tested it with ProLiant servers and its own top of rack (ToR) switches
- Uses existing CAT6A or better UTP cable per IEEE 802.3an, with shielded CAT6A advised for new installs
Also Supported
DPDK, TCP/IP stateless offloads, Tunnel offload (VXLAN, NVGRE), NVMe ready, MSI and MSI-X, Forward Error Correction (FEC), VMware NetQueue and Microsoft VMQ virtualization support, Auto negotiation, Checksum and segmentation offload, IPv6, RDMA, RSS, Precision Time Protocol (PTP), NIC teaming, Network Partitioning (NPAR)
Condition: Brand New in Factory Sealed Box
Warranty: Up to a 3-Years Manufacturer Warranty and a 30 Days Return Window through us
Part Numbers
Manufacturer: HPE
MPN: 827607-001
Option Part Number: N3U51A
Spare Part Number: 827607-001
General
Product Type: Converged Network Adapter
Adapter Type: Optical
Form Factor: Plug-in Card - Low Profile
Media: Cat6a cables, 10Gb SFP+ Ethernet Optical Modules (SR) or SFP+ direct attach active and passive copper cable
Adapter Details
Bus Type: PCIe (PCI Express)
Port Speed: 10GbE
Connectivity: Wired
Data Link Protocol: 10 Gigabit Ethernet, Fibre Channel over Ethernet (FCoE), 10Gb Converged Enhanced Ethernet (CEE)
Data Rate: 10 GbE / 25 GbE Ethernet
Protocols Supported: FCoE, Ethernet, iSCSI
Compliance: IEEE802.3x, IEEE802.3ad, IEEE802.1p, IEEE802.1q, IEEE802.3az, IEEE802.3ae, IEEE802.3ap, IEEE802.1qau, P802.1Qaz(ETS), P802.1Qbb(PFC), P802.1Qaz(DCBX)
Connections
PCIe Connector: PCIe x8 Gen3
Slot Type: x8 PCIe 3.0 or 2.0
Channels: Dual
In the Box: CNA, Low-Profile Bracket, Low-Profile Bracket, Full-Height Bracket
Connector Type: Dual
Ports: 10Gb Ethernet x 2, 2 x 10GBase-T
Cabling: Ethernet 10GBase-T
Supported Cables: SFP+ Ethernet Optical Modules or Direct Attach Copper
Software and Compatibility
Supported Operating Systems: Microsoft Windows Server 2016/2012/2012 R2 & Hyper V (x64), VMware (6.7,6.5,6.0,5.5) (x64), RHEL (Red Hat Linux 7.x, 6.x) (x64), SLES (SUSE Linux 12.x, 11.x) (x64) Power Up to six (6) 2650W power supplies providing up to 15,900W of power for the chassis
Size and Weight
Width: 0.90 inch
Depth: 7.20 inch
Height: 4.70 inch
Power and Environment
Operating Temp: 32º to 113º F (0º to 45º C)
Storage Temp: -40º F to 158º F (-40º to 70º C)
Operating Humidity: 15% to 80% (relative, non-condensing)
Compatible Systems
- HPE Apollo 4510 Gen10
- HPE ProLiant XL Series: XL170r Gen10, XL190r Gen10
- HPE StoreEasy 3850 Gateway Single Node
- Compatible Array Platforms: HPE MSA family, HPE XP family, HPE 3PAR family, HPE Nimble Storage family
- FCoE Switches Supported: HPE B-series converged network switches, HPE C-series converged network switches, HPE FlexFabric switches
Not sure this adapter fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
