Product Information
The Intel Celeron N6210 is a dual-core, 2-thread low power processor in an FCBGA1493 package. It runs at 1.2 GHz, has 1.5 MB of L2 cache and integrated Intel UHD Graphics, and draws just 6.5 W. It is suited to compact and fanless designs that need basic computing.
Key Features
- 2 cores and 2 threads
- 1.2 GHz clock speed
- 1.5 MB L2 cache, 10 nm process
- FCBGA1493 package, 8 PCIe 3.0 lanes
- Intel UHD Graphics, triple display capable
- OEM tray package, 6.5 W thermal design power
Product Information
Brand: Intel
Manufacturer: Intel
Product Type: Processor
Packaged Quantity: 1
Network and Communication
Features: Triple Display Capable
Connectivity
PCI Express Lanes Quantity: 8
PCI Express Revision: 3.0
Integrated Graphics: Intel UHD Graphics
Memory and Processor
Cache Details: L2 - 1.5 MB
Processor Main Features: Enhanced SpeedStep technology, Execute Disable Bit capability, Idle States, Intel 64 Technology, Intel AES New Instructions (AES-NI), Intel Boot Guard, Intel Secure Key, Intel Software Guard Extensions (SGX), Intel Virtualization Technology, Intel Virtualization Technology for Directed I/O (VT-d), Intel VT-x with Extended Page Tables (EPT), Streaming SIMD extensions 4.1, Streaming SIMD extensions 4.2, Thermal Monitoring Technologies
Cache: 1.5 megabyte
Threads: 2 threads
Graphics Base Frequency: 250 megahertz
Manufacturing Process: 10 nm
Compatible Processor Socket: FCBGA1493 Socket
Processor Package: OEM/tray
Thermal Design Power: 6.5 watt
Thermal Specification: 105 degree Celsius
Cores: Dual-core
Processor Brand: Intel
Processor Type: Celeron
Processor Number: N6210
Processors Installed: 1
Clock Speed: 1.2 GHZ
Technical Information
Max Supported Resolution: 4096x2160@60Hz (DP), 4096x2160@60Hz (eDP)
Certifications and Listing
ENERGY STAR Certified: No
TCO Certified: No
