Product Information
The Intel Core i5-14400 is a 14th generation desktop processor with 10 cores and 16 threads. It runs at 2.5 GHz with turbo up to 4.7 GHz, has 20 MB of Smart Cache and integrates Intel UHD Graphics 730 on the FCLGA1700 socket. Retail boxed with a 3 year limited warranty.
Key Features
- 10 cores and 16 threads
- 2.5 GHz base, up to 4.7 GHz turbo
- 20 MB Smart Cache plus 9.5 MB L2
- FCLGA1700 socket, 20 PCIe lanes, revision 4.0/5.0
- Intel UHD Graphics 730 with Quick Sync Video
- Intel boxed package, 3 year limited warranty listed
Product Information
Brand: Intel
Manufacturer: Intel
Product Type: Processor
Packaged Quantity: 1
Network and Communication
Features: Intel Clear Video HD Technology, Intel Quick Sync Video, Quad Display Capable
Connectivity
PCI Express Configurations: 1x16+4, 2x8+4
PCI Express Lanes Quantity: 20
PCI Express Revision: 4.0/5.0
Integrated Graphics: Intel UHD Graphics 730
Memory and Processor
Cache Details: L2 - 9.5 MB, Smart Cache - 20 MB
Processor Generation: 14
Processor Main Features: Enhanced SpeedStep technology, Execute Disable Bit capability, Hyper-Threading Technology, Idle States, Instruction Set 64-bit, Intel 64 Technology, Intel Advanced Vector Extensions 2 (AVX2.0), Intel AES New Instructions (AES-NI), Intel Boot Guard, Intel Control-Flow Enforcement Technology, Intel Deep Learning Boost (DL Boost), Intel Gaussian and Neural Accelerator 3.0, Intel OS Guard, Intel Secure Key, Intel Speed Shift Technology, Intel Standard Manageability (ISM), Intel Thread Director, Intel Turbo Boost Technology 2.0, Intel Virtualization Technology, Intel Virtualization Technology for Directed I/O (VT-d), Intel Volume Management Device (VMD), Intel VT-x with Extended Page Tables (EPT), Mode-based Execute Control (MBEC), Streaming SIMD extensions 4.1, Streaming SIMD extensions 4.2, Thermal Monitoring Technologies
Cache: 20 megabyte
Threads: 16 threads
Graphics Max Dynamic Frequency: 1.55 GHZ
Manufacturing Process: 10 nm
Compatible Processor Socket: FCLGA1700 Socket
Processor Package: Intel Boxed
Thermal Design Power: 148 watt
Thermal Specification: 100 degree Celsius
Max Turbo Speed: 4.7 GHZ
Cores: 10-core
Processor Brand: Intel
Processor Type: Core i5
Processor Number: I5-14400
Processors Installed: 1
Clock Speed: 2.5 GHZ
Technical Information
Max Supported Resolution: 4096x2160@60Hz (HDMI), 5120x3200@120Hz (eDP), 7680x4320@60Hz (DP)
Certifications and Listing
ENERGY STAR Certified: No
TCO Certified: No
Warranty
Limited Warranty: 3 Year
Service & Support Details: Limited warranty - 3 years
