Product Information
The Intel Core i7-12700F is a 12th generation desktop processor with 12 cores and 20 threads for the LGA1700 socket. It runs at 2.1 GHz with turbo up to 4.9 GHz and has 25 MB of Smart Cache. This boxed retail unit carries a 3 year limited warranty.
Key Features
- 12 cores and 20 threads
- 2.1 GHz base, up to 4.9 GHz turbo
- 25 MB Smart Cache plus 12 MB L2
- LGA1700 socket, 20 PCIe lanes, revision 4.0/5.0
- Intel Deep Learning Boost, Optane Memory support
- Intel boxed package, 3 year limited warranty listed
Product Information
Brand: Intel
Manufacturer: Intel
Product Type: Processor
Packaged Quantity: 1
Connectivity
PCI Express Configurations: 1x16+4, 2x8+4
PCI Express Lanes Quantity: 20
PCI Express Revision: 4.0/5.0
Memory and Processor
Cache Details: L2 - 12 MB, L3 - Smart Cache - 25 MB
Processor Generation: 12
Processor Main Features: Enhanced SpeedStep technology, Execute Disable Bit capability, Hyper-Threading Technology, Idle States, Instruction Set 64-bit, Intel 64 Technology, Intel Advanced Vector Extensions 2 (AVX2.0), Intel AES New Instructions (AES-NI), Intel Boot Guard, Intel Control-Flow Enforcement Technology, Intel Deep Learning Boost (DL Boost), Intel Gaussian and Neural Accelerator 3.0, Intel Optane Memory Supported, Intel OS Guard, Intel Secure Key, Intel Speed Shift Technology, Intel Thread Director, Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost Technology 2.0, Intel Virtualization Technology, Intel Virtualization Technology for Directed I/O (VT-d), Intel Volume Management Device (VMD), Intel VT-x with Extended Page Tables (EPT), Mode-based Execute Control (MBE), Streaming SIMD extensions 4.1, Streaming SIMD extensions 4.2, Thermal Monitoring Technologies
Cache: 25 megabyte
Threads: 20 threads
Manufacturing Process: 10 nm
Compatible Processor Socket: LGA1700 Socket
Processor Package: Intel Boxed
Thermal Design Power: 180 watt
Thermal Specification: 100 degree Celsius
Max Turbo Speed: 4.9 GHZ
Cores: 12-core
Processor Brand: Intel
Processor Type: Core i7
Processor Number: I7-12700F
Processors Installed: 1
Clock Speed: 2.1 GHZ
Certifications and Listing
ENERGY STAR Certified: No
TCO Certified: No
Warranty
Limited Warranty: 3 Year
Service & Support Details: Limited warranty - 3 years
Not sure this processor fits your system? Send us your server or motherboard model and current CPU, and the DatorPro team will confirm socket and platform compatibility before you order.
