Product Information
The Intel Core i7-14700K is an unlocked 14th generation processor with 20 cores and 28 threads. It runs at 3.4 GHz with turbo up to 5.6 GHz, has 33 MB of Smart Cache and integrates Intel UHD Graphics 770 on the FCLGA1700 socket. This OEM tray unit has a 1 year limited warranty.
Key Features
- 20 cores and 28 threads
- 3.4 GHz base, up to 5.6 GHz turbo
- 33 MB Smart Cache plus 28 MB L2
- FCLGA1700 socket, 20 PCIe lanes, revision 4.0/5.0
- Intel UHD Graphics 770, quad display capable
- OEM tray package, 1 year limited warranty listed
Product Information
Brand: Intel
Manufacturer: Intel
Product Type: Processor
Packaged Quantity: 1
Network and Communication
Features: Intel Clear Video HD Technology, Intel Quick Sync Video, Quad Display Capable
Connectivity
PCI Express Configurations: 1x16+4, 2x8+4
PCI Express Lanes Quantity: 20
PCI Express Revision: 4.0/5.0
Integrated Graphics: Intel UHD Graphics 770
Memory and Processor
Cache Details: L2 - 28 MB, Smart Cache - 33 MB
Processor Generation: 14
Processor Main Features: Enhanced SpeedStep technology, Execute Disable Bit capability, Hyper-Threading Technology, Idle States, Instruction Set 64-bit, Intel 64 Technology, Intel Advanced Vector Extensions 2 (AVX2.0), Intel AES New Instructions (AES-NI), Intel Boot Guard, Intel Control-Flow Enforcement Technology, Intel Deep Learning Boost (DL Boost), Intel Gaussian and Neural Accelerator 3.0, Intel OS Guard, Intel Secure Key, Intel Speed Shift Technology, Intel Standard Manageability (ISM), Intel Thread Director, Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost Technology 2.0, Intel Virtualization Technology, Intel Virtualization Technology for Directed I/O (VT-d), Intel Volume Management Device (VMD), Intel VT-x with Extended Page Tables (EPT), Mode-based Execute Control (MBE), Streaming SIMD extensions 4.1, Streaming SIMD extensions 4.2, Thermal Monitoring Technologies
Cache: 33 megabyte
Threads: 28 threads
Graphics Base Frequency: 300 megahertz
Graphics Max Dynamic Frequency: 1.6 GHZ
Compatible Processor Socket: FCLGA1700 Socket
Processor Package: OEM/tray
Thermal Design Power: 253 watt
Thermal Specification: 100 degree Celsius
Max Turbo Speed: 5.6 GHZ
Cores: 20-core
Processor Brand: Intel
Processor Type: Core i7
Processor Number: I7-14700K
Processors Installed: 1
Clock Speed: 3.4 GHZ
Technical Information
Max Supported Resolution: 4096x2160@60Hz (HDMI), 5120x3200@120Hz (eDP), 7680x4320@60Hz (DP)
Certifications and Listing
ENERGY STAR Certified: No
TCO Certified: No
Warranty
Limited Warranty: 1 Year
Service & Support Details: Limited warranty - 1 year
Not sure this processor fits your system? Send us your server or motherboard model and current CPU, and the DatorPro team will confirm socket and platform compatibility before you order.
