Product Information
The Intel Core i7-14700T is a low power 14th generation processor with 20 cores and 28 threads for the FCLGA1700 socket. It has a 35 W base power and 106 W maximum turbo power, a 1.3 GHz base clock and turbo up to 5.2 GHz with Turbo Boost Max 3.0. Integrated Intel UHD Graphics 770 supports up to 8K output, and memory support reaches 192 GB using DDR5 at 5600 MT/s or DDR4 at 3200 MT/s.
Key Features
- 20 cores and 28 threads, hybrid design
- 1.3 GHz base, up to 5.2 GHz turbo
- 35 W base power, 106 W maximum turbo power
- 33 MB Smart Cache plus 28 MB L2
- Intel UHD Graphics 770, quad display capable
- FCLGA1700 socket, OEM tray package
Product Information
Brand: Intel
Manufacturer: Intel
Product Type: Processor
Packaged Quantity: 1
Network and Communication
Features: Intel Clear Video HD Technology, Intel Quick Sync Video, Quad Display Capable
Connectivity
PCI Express Configurations: 1x16+4, 2x8+4
PCI Express Lanes Quantity: 20
PCI Express Revision: 4.0/5.0
Integrated Graphics: Intel UHD Graphics 770
Memory and Processor
Cache Details: L2 - 28 MB, Smart Cache - 33 MB
Processor Generation: 14
Processor Main Features: Direct Media Interface (DMI), Enhanced SpeedStep technology, Execute Disable Bit capability, Hyper-Threading Technology, Idle States, Instruction Set 64-bit, Intel 64 Technology, Intel Advanced Vector Extensions 2 (AVX2.0), Intel AES New Instructions (AES-NI), Intel Boot Guard, Intel Control-Flow Enforcement Technology, Intel Deep Learning Boost (DL Boost), Intel Gaussian and Neural Accelerator 3.0, Intel OS Guard, Intel Secure Key, Intel Speed Shift Technology, Intel Standard Manageability (ISM), Intel Thread Director, Intel Trusted Execution Technology, Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost Technology 2.0, Intel Virtualization Technology, Intel Virtualization Technology for Directed I/O (VT-d), Intel Volume Management Device (VMD), Intel VT-x with Extended Page Tables (EPT), Mode-based Execute Control (MBE), Multi-format codec engines, Streaming SIMD extensions 4.1, Streaming SIMD extensions 4.2, Thermal Monitoring Technologies
Cache: 33 megabyte
Threads: 28 threads
Graphics Base Frequency: 300 megahertz
Graphics Max Dynamic Frequency: 1.6 GHZ
Manufacturing Process: 7 nm
Compatible Processor Socket: FCLGA1700 Socket
Processor Package: OEM/tray
Thermal Design Power: 106 watt
Thermal Specification: 100 degree Celsius
Max Turbo Speed: 5.2 GHZ
Cores: 20-core
Processor Brand: Intel
Processor Type: Core i7
Processor Number: I7-14700T
Processors Installed: 1
Clock Speed: 1.3 GHZ
Technical Information
Max Supported Resolution: 4096x2160@60Hz (HDMI), 5120x3200@120Hz (eDP), 7680x4320@60Hz (DP)
Certifications and Listing
ENERGY STAR Certified: No
TCO Certified: No
Not sure this processor fits your system? Send us your server or motherboard model and current CPU, and the DatorPro team will confirm socket and platform compatibility before you order.
