Product Information
Intel's E835-CQDA2 Ethernet Network Adapter has two ports that support 10, 25, 50, 100 and 200 Gb Ethernet. It offers PTP and Synchronous Ethernet timing, DPDK, Dynamic Device Personalization, Flexible Port Partitioning, OVS offload, SR-IOV and on chip QoS, with hardware root of trust, secure boot and signed firmware. The listing labels the ports QSFP28 while quoting 200G speeds, and does not give the host interface, so please confirm before ordering.
Key Features
- 2 x 200GbE ports
- 10 to 200 GbE speeds
- PTP and SyncE timing
- DPDK and DDP
- Hardware root of trust
- Intel E835 controller
Product Information
Brand: Intel
Manufacturer: Intel
Product Line: Intel Ethernet Network Adapter
Model: E835-CQDA2
Product Type: Network adapter
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, 100 Gigabit InfiniBand, 200 Gigabit Ethernet, 25 Gigabit Ethernet, 50 Gigabit Ethernet
Features: Data Plane Development Kit (DPDK), Distributed Management Task Force (DTMF), Dynamic Device Personalization (DDP), Flexible Port Partitioning (FPP), Hardware root of trust, MCTP over SMBus, On-chip QoS and Traffic Management, Open Virtual Switch (OVS), PCI-SIG SR-IOV-ready, Precision Time Protocol (PTP), Secure Boot, Signed firmware, Synchronous Ethernet (SyncE), Virtual Machine Device Queues (VMDq), Virtualization Technology for Connectivity (VT-c)
Connectivity
PCI Specification Revision: PCIe 4.0, PCIe 5.0
Port Quantity: 2
Interface Provided: 2 x 200Gb Ethernet - QSFP28
Network & Adapter Ports: 10/25/50/100/200 Gigabit QSFP28
Physical Characteristics
Form Factor: Plug-In Card
Certifications and Listing
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
