Product Information
The Intel Killer Wi-Fi 7 BE1750x is an M.2 2230 plug in card adding Wi-Fi 7 on 2.4, 5 and 6 GHz plus Bluetooth 5.4. It supports Multi-Link Operation, 320 MHz channels and up to 5.8 Gbps, with FIPS 140-3 listed. This is a network adapter card for a PC, not a router.
Key Features
- Wi-Fi 7, 2.4, 5 and 6 GHz
- Up to 5.8 Gbps, 320 MHz, 4096 QAM
- Multi-Link Operation, puncturing, MRU
- Bluetooth 5.4
- M.2 2230, 2x2 MU-MIMO
- Windows 10 / 11 and Linux
Product Information
Brand: Intel
Manufacturer: Intel
Product Line: Intel Killer Wi-Fi 7
Model: BE1750x
Product Type: Network adapter
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: Bluetooth 5.4, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11be (Wi-Fi 7), IEEE 802.11g, IEEE 802.11n
Encryption: 128-bit AES-CCMP, 256-bit AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, FIPS 140-3, MSCHAPv2, PEAP, WPA2, WPA3-Enterprise, WPA3-Personal
Data Transfer Rate: 5.8 GBps
Line Coding Format: 4096 QAM, OFDMA
Performance: Channel bandwidth: 320 mhz
Network Band: 2.4 GHz, 5 GHz, 6 GHz
Spread Spectrum Method: OFDMA
Operating System Required: Linux, Microsoft Windows 10 / 11
Features: 2x2 MU-MIMO technology, 802.1x authentication, Multi-Link Operation (MLO), Multiple Resource Unit (MRU), Puncturing transmission, Wireless radio enable/disable
Connectivity
Host Interface: M.2 2230
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 176 degree Fahrenheit
Physical Characteristics
Form Factor: Plug-In Card
Dimensions and Weight
Weight: 0.11 ounce
Certifications and Listing
Compliant Standards #2: CB 62368-1, cUL, FIPS, UL
Compliant Standards: Bluetooth 5.4, IEEE 802.11, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w, Wi-Fi CERTIFIED 7
Compliant Standards: CB 62368-1, cUL, FIPS, UL
Warranty
Service Activation: No
