Product Information
The Intel Wi-Fi 7 BE200 is an M.2 2230 plug in card that adds Wi-Fi 7 on the 2.4, 5 and 6 GHz bands and Bluetooth 5.4 to a compatible PC. It supports 320 MHz channels, 4096 QAM and data rates up to 5.8 Gbps. This is a network adapter card, not a router, and it carries a 1 year limited warranty.
Key Features
- Wi-Fi 7 (802.11be), 2.4, 5 and 6 GHz
- Up to 5.8 Gbps, 320 MHz channels, 4096 QAM
- Bluetooth 5.4
- M.2 2230 plug in card, 2x2 MU-MIMO
- Windows 10, Windows 11 and Linux
- 1 year limited warranty
Product Information
Brand: Intel
Manufacturer: Intel
Product Line: Intel Wi-Fi 7
Model: BE200
Product Type: Network adapter
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: Bluetooth 5.4, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11be (Wi-Fi 7), IEEE 802.11g, IEEE 802.11n
Encryption: 128-bit AES-CCMP, 256-bit AES-GCMP, EAP-AKA, EAP-MSCHAPv2, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3-Enterprise, WPA3-Personal
Data Transfer Rate: 5.8 GBps
Line Coding Format: 1024 QAM, 16 QAM, 256 QAM, 4096 QAM, 64 QAM, BPSK, OFDMA, QPSK
Performance: Channel bandwidth: 320 mhz
Network Band: 2.4 GHz, 5 GHz, 6 GHz
Spread Spectrum Method: OFDMA
Operating System Required: Linux, Windows 10, Windows 11
Features: 2x2 MU-MIMO technology, 802.1x authentication, Protected management frames, Wi-Fi Agile Multiband, Wi-Fi Direct, Wi-Fi Multimedia (WMM) support, Wireless radio enable/disable, WMM Power Save
Connectivity
Host Interface: M.2 2230
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 176 degree Fahrenheit
Operating Humidity: 50 - 90% RH (non-condensing)
Physical Characteristics
Form Factor: Plug-In Card
Dimensions and Weight
Height: 0.9 inch
Width: 1.2 inch
Depth: 0.1 inch
Weight: 0.1 ounce
Certifications and Listing
Compliant Standards #2: CB, cUL, FIPS, FIPS 140-2, IEC 60950-1, UL, WEEE, WFA
Compliant Standards: Bluetooth 5.4, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b, IEEE 802.11be, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w, Wi-Fi CERTIFIED 6, Wi-Fi CERTIFIED 6E, Wi-Fi CERTIFIED 7
Compliant Standards: CB, cUL, FIPS, FIPS 140-2, IEC 60950-1, UL, WEEE, WFA
Warranty
Limited Warranty: 1 Year
Service & Support Details: Limited warranty - 1 year
Service Activation: No
