Product Information
The Intel Xeon E-2436 is a 6-core, 12-thread processor for entry servers on the FCLGA1700 socket. It runs at 2.9 GHz with turbo up to 5 GHz, has 18 MB of Smart Cache and offers 20 PCIe 5.0 lanes at a 65 W thermal design power. This is the OEM tray version.
Key Features
- 6 cores and 12 threads
- 2.9 GHz base, up to 5 GHz turbo
- 18 MB Smart Cache
- FCLGA1700 socket, 20 PCIe 5.0 lanes
- Trusted Execution, AES-NI, Boot Guard
- OEM tray package, 65 W thermal design power
Product Information
Brand: Intel
Manufacturer: Intel
Product Type: Processor
Packaged Quantity: 1
Connectivity
PCI Express Configurations: 1x16+1x4, 2x8+1x4
PCI Express Lanes Quantity: 20
PCI Express Revision: 5.0
Memory and Processor
Cache Details: Smart Cache - 18 MB
Processor Main Features: Enhanced SpeedStep technology, Execute Disable Bit capability, Idle States, Intel 64 Technology, Intel Advanced Vector Extensions 2 (AVX2.0), Intel AES New Instructions (AES-NI), Intel Boot Guard, Intel Memory Protection Extensions (MPX), Intel Optane Memory Supported, Intel OS Guard, Intel Secure Key, Intel Transactional Synchronization Extensions (TSX), Intel Trusted Execution Technology, Intel TSX-NI, Intel Turbo Boost Technology 2.0, Intel Virtualization Technology, Intel Virtualization Technology for Directed I/O (VT-d), Intel VT-x with Extended Page Tables (EPT), Streaming SIMD extensions 4.1, Streaming SIMD extensions 4.2, Thermal Monitoring Technologies
Cache: 18 megabyte
Threads: 12 threads
Manufacturing Process: 7 nm
Compatible Processor Socket: FCLGA1700 Socket
Processor Package: OEM/tray
Thermal Design Power: 65 watt
Thermal Specification: 100 degree Celsius
Max Turbo Speed: 5 GHZ
Cores: 6-core
Processor Brand: Intel
Processor Type: Xeon
Processor Number: E-2436
Processors Installed: 1
Clock Speed: 2.9 GHZ
Certifications and Listing
ENERGY STAR Certified: No
TCO Certified: No
Not sure this processor fits your system? Send us your server or motherboard model and current CPU, and the DatorPro team will confirm socket and platform compatibility before you order.
