Product Information
The Intel Xeon w5-3525 is a 16-core, 32-thread workstation processor on the FCLGA4677 socket. It runs at 3.2 GHz with turbo up to 4.8 GHz and carries 45 MB of Smart Cache, with 112 PCIe 5.0 lanes available. This unit is the OEM tray version.
Key Features
- 16 cores and 32 threads
- 3.2 GHz base, up to 4.8 GHz turbo
- 45 MB Smart Cache
- FCLGA4677 socket, 112 PCIe 5.0 lanes
- Intel AMX, Deep Learning Boost, Active Management Technology
- OEM tray package
Product Information
Brand: Intel
Manufacturer: Intel
Product Type: Processor
Packaged Quantity: 1
Connectivity
PCI Express Lanes Quantity: 112
PCI Express Revision: 5.0
Memory and Processor
Cache Details: Smart Cache - 45 MB
Processor Main Features: Enhanced SpeedStep technology, Execute Disable Bit capability, Hyper-Threading Technology, Instruction Set 64-bit, Intel 64 Technology, Intel Active Management Technology, Intel Advanced Matrix Extensions (AMX), Intel AES New Instructions (AES-NI), Intel Boot Guard, Intel Control-Flow Enforcement Technology, Intel Data Streaming Accelerator (DSA), Intel Deep Learning Boost (DL Boost), Intel OS Guard, Intel Platform Firmware Resilience Support, Intel Speed Shift Technology, Intel Total Memory Encryption, Intel Transactional Synchronization Extensions (TSX), Intel Trusted Execution Technology, Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost Technology 2.0, Intel Virtualization Technology, Intel Virtualization Technology for Directed I/O (VT-d), Intel Virtualization Technology with Redirect Protection (VT-rp), Intel vPro Enterprise Platform Eligibility, Intel VT-x with Extended Page Tables (EPT), Mode-based Execute Control (MBEC)
Cache: 45 megabyte
Threads: 32 threads
Compatible Processor Socket: FCLGA4677 Socket
Processor Package: OEM/tray
Thermal Design Power: 348 watt
Thermal Specification: 72 degree Celsius
Max Turbo Speed: 4.8 GHZ
Cores: 16-core
Processor Brand: Intel
Processor Type: Xeon W
Processor Number: W5-3525
Processors Installed: 1
Clock Speed: 3.2 GHZ
Certifications and Listing
ENERGY STAR Certified: No
TCO Certified: No
Not sure this processor fits your system? Send us your server or motherboard model and current CPU, and the DatorPro team will confirm socket and platform compatibility before you order.
