Product Information
Juniper's EX3400-24P is a 1U Layer 3 access switch with 24 Gigabit PoE+ ports, four 10G SFP+ ports and two 40G QSFP+ uplinks. It has a 370 W PoE budget and supports redundant power supplies.
Key Features
- 24 x Gigabit RJ-45 PoE+ ports
- 4 x 10G SFP+ ports
- 2 x 40G QSFP+ uplinks
- 370 W PoE budget
- Layer 3 managed
- Redundant power supported
Product Information
Brand: Juniper
Manufacturer: Juniper Networks, Inc
Series: EX3400
Model: EX3400-24P
Product Type: Layer 3 Switch
Network and Communication
Data Link Protocols: 10 Gigabit Ethernet, 40 Gigabit Ethernet, Gigabit Ethernet
Network Technology: 10/100/1000Base-T, 10GBase-X, 40GBase-X
Layer Supported: 3
Manageable: Yes
Connectivity
Expansion Slot Type: QSFP+, SFP+
Expansion Slot Details: 2 x 40 Gigabit Ethernet Uplink, 24 x Gigabit Ethernet Network, 4 x 10 Gigabit Ethernet Expansion Slot
SFP+ Slots: 4
Shared SFP Slot: No
Uplink Port: Yes
Stack Port: Yes
Power
Power Source: Power Supply
Power Consumption: 110 watt
PoE Budget: 370 watt
Redundant Power Supply Supported: Yes
Physical Characteristics
Form Factor: Rack-mountable, Wall Mountable
Rack Unit: 1U
Dimensions and Weight
Height: 1.7 inch
Width: 17.4 inch
Depth: 13.8 inch
Weight: 10.49 lb
Certifications and Listing
Environmentally Friendly: Yes
Warranty
Limited Warranty: Lifetime
Not sure this fits your network? Send us your current switch, router or chassis model and the DatorPro team will confirm compatibility before you order.
