Product Information
The Juniper EX4600-40F-AFO is a 1U Layer 3 switch with 24 SFP+ ports at 10GbE and four QSFP+ ports at 40GbE on the base unit. It runs Junos and can be managed by CLI, SSH, SNMP or Junos Space Network Director. This AFO version uses airflow out cooling and supports redundant power supplies.
Key Features
- 24 x 10GbE SFP+ ports
- 4 x 40GbE QSFP+ ports
- Layer 3 managed (Junos)
- Management port and USB port
- 1U, AFO airflow
- Redundant power supported
Product Information
Brand: Juniper
Manufacturer: Juniper Networks, Inc
Series: EX
Model: EX4600-40F-AFO
Product Type: Layer 3 Switch
Network and Communication
Data Link Protocols: 10 Gigabit Ethernet, 40 Gigabit Ethernet
Network Technology: 10GBase-X, 40GBase-X
Layer Supported: 3
Manageable: Yes
Management: Junos Space Network Director,Command Line Interface (CLI),Telnet,SSH,SNMP v1/v2/v3,sFlow v5,MIB,QoS,RMON,VLAN
Bypass: No
Connectivity
Expansion Slot Type: QSFP+, SFP+
Expansion Slot Details: 24 x 10 Gigabit Ethernet Expansion Slot, 4 x 40 Gigabit Ethernet Expansion Slot
PoE (RJ-45) Port: No
SFP+ Slots: 24
Management Port: Yes
USB: Yes
LRE Port: No
Token Ring Port: No
Power
Power Source: Power Supply
Redundant Power Supply Supported: Yes
Physical Characteristics
Form Factor: Rack-mountable
Rack Unit: 1U
Dimensions and Weight
Height: 1.7 inch
Width: 17.4 inch
Depth: 20.5 inch
Weight: 21.40 lb
Certifications and Listing
Environmentally Friendly: Yes
Warranty
Limited Warranty: 1 Year
