Product Information
The Lantronix EDS4100 (ED41000P0-01) is a 4 port external device server that brings serial equipment onto the network for secure remote access and management. It has two RS-232 DB-9 ports, two RS-232/422/485 DB-9 ports and one 10/100 RJ-45 port with PoE, so it can run without a power supply (none is included per the quick specs). It runs Lantronix Evolution OS on a 266 MHz processor with 32 MB SDRAM and 8 MB flash, supports full or half duplex, and offers SSH v2, SSL 3.0, AES, 3DES and ARCFOUR encryption. Management is by web, Telnet and SNMP v2, with DHCP, BOOTP and ARP support.
Key Features
- 4 serial ports, DB-9
- 2 x RS-232, 2 x RS-232/422/485
- 10/100 Ethernet with PoE
- Evolution OS, SSH v2
- AES and SSL encryption
- Web, Telnet, SNMP
Product Information
Brand: Lantronix
Manufacturer: Lantronix
Product Line: Lantronix Device Server EDS4100
Product Type: Device server
Packaged Quantity: 1
Network and Communication
Communication Mode: Full-duplex, Half-duplex
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, RS-232, RS-422, RS-485
Network Standard: ICMP/IP, TCP/IP, UDP/IP
Remote Management: HTTP, SNMP 2, Telnet
Authentication Method: Secure Shell v.2 (SSH2)
Encryption: AES, ARCFOUR, SSL 3.0, Triple DES
Operating System Required: Microsoft Windows 98/ME/NT/2000/XP
Features: 128-bit encryption, ARP support, BOOTP support, DHCP support
Software Type: Drivers & Utilities
Connectivity
Ports: 4
Interface Provided: 1 x 100Base-TX - RJ-45, 2 x RS-232 - DB-9, 2 x RS-232/422/485 - DB-9
Power Over Ethernet (PoE): PoE
Memory and Processor
Processors Installed: 1
Clock Speed: 266 megahertz
RAM Installed: 32 megabyte
Memory Technology: SDRAM
Flash Memory Installed: 8 megabyte
Total Processor Supported: 1
Optical Drive Type: None
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 131 degree Fahrenheit
Operating Humidity: 10 - 90%
Physical Characteristics
Form Factor: External
Status Indicators: Link/activity, Power, Test mode
Dimensions and Weight
Height: 5 inch
Width: 7 inch
Depth: 1.5 inch
Weight: 1.98 lbs
Certifications and Listing
Compliant Standards #2: C-Tick, CISPR 22, cUL, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024, FCC Part 15, ICES-003 Class A, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, RoHS, TUV GS, UL, VCCI
Compliant Standards: IEEE 802.3af
Compliant Standards: C-Tick, CISPR 22, cUL, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024, FCC Part 15, ICES-003 Class A, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, RoHS, TUV GS, UL, VCCI
