Product Information
Lantronix's LM80 (80-8S-NNN-NAA) is a console server and local manager with eight RJ-45 serial ports for out-of-band access to network gear. It offers Smart Out-of-Band, failover, VPN support and zero touch deployment, with 256 GB of onboard flash. This is a console server, not a switch.
Key Features
- 8 x RJ-45 serial console ports
- Smart Out-of-Band management
- Failover and VPN support
- Zero touch deployment
- 256 GB flash storage
- Integrated power supply
Product Information
Brand: Lantronix
Manufacturer: Lantronix
Product Line: Lantronix LM series
Model: LM80
Product Type: Gateway
Packaged Quantity: 1
Color Category: Black, Gray
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232
Wired Protocol: 10/100/1000 Ethernet
Authentication Method: RADIUS, Secure Shell v.2 (SSH2), TACACS
Encryption: 256-bit AES
Internet of Things (IoT) Compatible: Yes
Antennas: 2
Antenna Form Factor: External detachable
Features: Dedicated Peripheral Port, Failover support, Intrusion Prevention System (IPS), Point-to-Point Protocol (PPP), Power-on self-test (POST), Smart Out-of-Band, VPN support
Connectivity
Interfaces: 2 x antenna, 2 x Gigabit Ethernet, 8 x serial (RS-232), Console, Gigabit Ethernet, USB-A, USB-C
Power
Power Source: Integrated power supply
Required Voltage: AC 100-240 volt
Memory and Processor
Flash Memory Installed: 256 GB
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 113 degree Fahrenheit
Operating Humidity: 20 - 80% RH (non-condensing)
Dimensions and Weight
Height: 1.7 inch
Width: 10 inch
Depth: 6.4 inch
Weight: 2.65 lbs
Certifications and Listing
Compliant Standards: FCC Class A certified, OPAL 2.0, RoHS, TCG Certified, TUV
