Product Information
The Lantronix TN-SFP-LX1T is a 1000Base-LX SFP optic for Gigabit Ethernet over single mode fiber at 1310 nm, with a duplex LC connector and reach up to 6.2 miles (10 km). It is hot pluggable, offers digital diagnostics (DMI), has an 11.5 dB link budget and runs from -40 to 85 °C. It is TAA compliant.
Key Features
- 1000Base-LX long reach
- 1310 nm, LC single mode
- Reach up to 10 km
- -40 to 85 °C operation
- Digital diagnostics (DMI)
- TAA compliant
Product Information
Brand: Lantronix
Manufacturer: Transition Networks
Product Line: Lantronix TN-SFP-LX Series
Product Type: SFP (mini-GBIC) transceiver module
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Gigabit Ethernet
Cable Type: Ethernet 1000Base-LX
Data Transfer Rate: 1 GBps
Max Transfer Distance: 6.2 miles
Optical Wave Length: 1310 nm
Features: 11.5 dB link budget, Digital Diagnostic Function (DMI), Hot-pluggable
Connectivity
Interface Provided: 1 x Ethernet 1000Base-LX - LC single-mode female x 2
Left Connector SD Type: LC single-mode
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 185 degree Fahrenheit
Physical Characteristics
Form Factor: Plug-In Module
Dimensions and Weight
Height: 0.3 inch
Width: 0.5 inch
Depth: 2.2 inch
Certifications and Listing
Compliant Standards #2: CFR 1040.10, CFR 1040.11, FDA 21, IEC 60825, MSA, NDAA, UL
Compliant Standards: IEEE 802.3
Compliant Standards: CFR 1040.10, CFR 1040.11, FDA 21, IEC 60825, MSA, NDAA, UL
TAA Compliant: Yes
Warranty
Limited Warranty: Limited Lifetime
Service & Support Details: Limited warranty - lifetime
Service Activation: No
