Product Information
The Lenovo ThinkSystem Intel E810-DA2 adapter (4XC7A08294) is a dual port SFP28 card in the OCP 3.0 form factor, with each port running at 10 or 25 Gb Ethernet. It supports RDMA with iWARP, SR-IOV, VMDq, VM load balancing, VXLAN and advanced packet filtering, with hardware root of trust and UEFI support. Listed systems include Lenovo ThinkAgile MX and VX appliances and certified nodes, with Windows Server 2016 and 2019, Red Hat and SUSE support.
Key Features
- 2 x 10/25GbE SFP28 ports
- Intel E810 controller
- OCP 3.0 form factor
- iWARP RDMA and SR-IOV
- Hardware root of trust
- For Lenovo ThinkAgile
Product Information
Brand: Intel
Manufacturer: Lenovo
Product Line: Lenovo ThinkSystem
Model: Intel E810-DA2
Product Type: Network adapter
Compatibility Specs: Lenovo ThinkAgile MX3330-F Appliance 7D19 ¦ Lenovo ThinkAgile MX3330-H Appliance 7D19 ¦ Lenovo ThinkAgile MX3331-F Certified Node 7D67 ¦ Lenovo ThinkAgile MX3331-H Certified Node 7D67 ¦ Lenovo ThinkAgile VX2330 Appliance 7Z62 ¦ Lenovo ThinkAgile VX3330 Appliance 7Z62 ¦ Lenovo ThinkAgile VX3331 7Z62 ¦ Lenovo ThinkAgile VX3530-G Appliance 7Z63 ¦ Lenovo ThinkAgile VX3575-G Integrated System 7D43 ¦ Lenovo ThinkAgile VX5530 Appliance 7Z63 ¦ Lenovo ThinkAgile VX5575 Integrated System 7D43 ¦ Lenovo ThinkAgile VX7330-N Appliance 7Z62 ¦ Lenovo ThinkAgile VX7530 Appliance 7Z63 ¦ Lenovo ThinkAgile VX7531 Certified Node 7Z63 ¦ Lenovo ThinkAgile VX7575 Integrated System 7D43 ¦ Lenovo ThinkAgile VX7576 Certified Node 7D43 ¦ Lenovo ThinkSystem SR630 V2 7Z70, 7Z71 ¦ Lenovo ThinkSystem SR645 7D2X, 7D2Y ¦ Lenovo ThinkSystem SR650 V2 7D15, 7Z72, 7Z73 ¦ Lenovo ThinkSystem SR665 7D2W ¦ Lenovo ThinkSystem SR670 V2 7Z22, 7Z23
Packaged Quantity: 1
Color Category: Green, Silver
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, 25 Gigabit Ethernet
Network Standard: iSCSI, iWARP, TCP/IP
Data Transfer Rate: 25 GBps
Operating System Required: Microsoft Windows Server 2016, Microsoft Windows Server 2019, Red Hat Enterprise Linux 7.6, Red Hat Enterprise Linux 7.7, Red Hat Enterprise Linux 7.8, Red Hat Enterprise Linux 7.9, Red Hat Enterprise Linux 8.1, Red Hat Enterprise Linux 8.2, Red Hat Enterprise Linux 8.3, SUSE Linux Enterprise Server 12 SP5, SUSE Linux Enterprise Server 12 SP5 with Xen, SUSE Linux Enterprise Server 15 SP1, SUSE Linux Enterprise Server 15 SP1 with Xen, SUSE Linux Enterprise Server 15 SP2, SUSE Linux Enterprise Server 15 SP2 with Xen, SUSE Linux Enterprise Server 15 SP3, SUSE Linux Enterprise Server 15 SP3 with Xen, VMware vSphere Hypervisor 6.7 (ESXi) Update 3, VMware vSphere Hypervisor 7.0 (ESXi), VMware vSphere Hypervisor 7.0 (ESXi) Update 1, VMware vSphere Hypervisor 7.0 (ESXi) Update 2
Features: Advanced Packet Filtering, Hardware root of trust, MCTP over SMBus, RDMA support, Single Root I/O Virtualization (SR-IOV), UEFI support, Virtual Extensible LAN (VXLAN), Virtual Machine Device Queues (VMDq), VM Load Balancing (VMLB)
Connectivity
PCI Specification Revision: PCIe 4.0
Port Quantity: 2
Interface Provided: 2 x 10Gb Ethernet/25Gb Ethernet - SFP28
Network & Adapter Ports: 10/25 Gigabit SFP28
Host Interface: Open Compute Project mezzanine (OCP) 3.0
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 131 degree Fahrenheit
Physical Characteristics
Form Factor: Plug-In Card
Dimensions and Weight
Width: 3 inch
Depth: 4.5 inch
Certifications and Listing
Compliant Standards: BSMI, FCC Subpart B, IEEE 1588, KCC, RCM, UL, VCCI
Warranty
Limited Warranty: 1 Year
Service & Support Details: Limited warranty - 1 year
Not sure this adapter or module fits your system? Send us your server, switch or storage model and the DatorPro team will confirm compatibility before you order.
