Product Information
The Lumens VC-A71SN is a black 4K PTZ camera (4096 x 2160 at up to 59.94 fps) with 30x optical zoom, built for conference rooms, lecture capture and live production. Outputs include 12G-SDI, HDMI and USB 3.0, with NDI|HX3 streaming, FreeD tracking data, 256 presets and RS-232/RS-422 control, on 12 V DC or PoE++. TAA compliant. It is a conference/production camera, not a security camera.
Key Features
- 4K at 59.94 fps
- 30x optical zoom
- 12G-SDI, HDMI, USB 3.0
- NDI|HX3 and FreeD
- 256 presets
- 12 V DC or PoE++, TAA
Product Information
Brand: Lumens
Manufacturer: LUMENS
Product Line: Lumens
Model: VC-A71SN
Packaged Quantity: 1
Color: Black
Color Category: Black
Network and Communication
Connectivity Technology: Wired
Features: 256 preset positions, 3D digital noise reduction (DNR), Auto gain control, Auto white balance, FreeD protocol support, Image flip, Manual gain control, Manual white balance, NDI|HX3 technology, PELCO D protocol support, PoE++ support, Tally light, VISCAIP protocol support, Webcam Support (UVC), Wide Dynamic Range (WDR)
Connectivity
Network Interface: LAN
Protocols: NDI, RTMP, RTMPS, RTSP, SRT
Ports: 12G-SDI, Audio line in - 3.5 mm jack, HDMI output, LAN, Serial RS-232 input, Serial RS-232 output, Serial RS-422 - terminal block, USB 3.0 - 9 pin USB Type B
Host Interface: USB 3.0
Technical Information
Angular Field of View (D, Max, Degree): 72.3
Angular Field of View (H, Max, Degree): 63
Angular Field of View (V, Max, Degree): 35.4
Focus Modes: Automatic, Manual
Video Signals: 12G-SDI, HDMI
Angular Field of View (D, Min, Degree): 4.2
Max Focal Length: 202 millimetre
Optical Zoom: 30
Control Interface: RS-232, RS-422, VISCA
Camera Type: Conference camera
Digital Zoom: 12
Max Panning Speed (degree/sec): 300
Max Tilting Speed (degree/sec): 300
Tilt: -30 to +90
Panning Range (degree): -170 to +170
Angular Field of View (H, Min, Degree): 3.7
Angular Field of View (V, Min, Degree): 2.1
Min Focus Distance: 5 ft
Minimum Illumination: 0.05 lux F1.6 - 50 IRE
Total Pixels: 9,170,000 pixels
Video Modes: 1080/25p, 1080/30p, 1080/50i, 1080/50p, 1080/59.54p, 1080/59.94i, 2160/25p, 2160/29.97p, 2160/50p, 2160/59.94p, 720/50p, 720/59.94p
Image Sensor Size: 1/1.8"
Image Sensor Type: CMOS
Lens Aperture: F/1.6-4.8
Min Focal Length: 6.5 millimetre
Sensor Size (metric): 14.1 mm (1/1.8")
Max Frame Rate: 59.94 frames per second
Shutter Speed (Max): 1/10000 second (time unit)
Shutter Speed (Min): 1/1 second (time unit)
Video Formats: H.264, HEVC, MJPEG, MPEG-TS
Video Input: Color
Audio Support: Yes
Audio Formats: G.711
Touchscreen: No
Max Video Resolution: 4096 x 2160
Physical Characteristics
Theft Protection: Security lock slot (cable lock sold separately)
Security Slot Type: Kensington security slot
Camera Mechanical Design: Pan / tilt / zoom
Dimensions and Weight
Height: 7.4 inch
Width: 9.1 inch
Depth: 7.4 inch
Weight: 6.61 lbs
Certifications and Listing
Compliant Standards: BT.2020 Colorimetry, IEEE 802.3bt
TAA Compliant: Yes
Not sure this camera fits your setup? Send us the model of your NVR, VMS or current cameras and how you plan to mount and power it, and the DatorPro team will help you confirm compatibility before you order.
