Product Information
The Lumens VC-TR41N (VC-TR41NW) is a 1080p60 PTZ camera with 20x optical zoom and AI tracking, auto framing and gesture control, for meeting rooms and lecture capture. It outputs 3G-SDI, HDMI and USB 3.0, supports RS-232/RS-422 control and 256 presets, and runs on 12 V DC or PoE. TAA and NDAA listed. It is a conference camera, not a security camera.
Key Features
- 1080p at 60 fps
- 20x optical zoom
- AI tracking, framing
- 3G-SDI, HDMI, USB 3.0
- 256 presets
- PoE, TAA and NDAA
Product Information
Brand: Lumens
Manufacturer: LUMENS
Product Line: Lumens
Model: VC-TR41N
Packaged Quantity: 1
Color: Black
Color Category: Black
Network and Communication
Connectivity Technology: Wired
Features: >50 dB SNR, 256 preset positions, 3D digital noise reduction (DNR), AI Tracking, Auto exposure control, Auto framing, Auto gain control, Auto white balance, Everywhere tracking mode, Gesture Control, Image flip, Manual exposure, Manual gain control, Manual white balance, ONVIF support, Partition tracking mode, Presenter Mode, Stage tracking mode, USB audio class (UAC), USB video class (UVC 1.1), Wide Dynamic Range (WDR)
Connectivity
Network Interface: LAN
Protocols: HTTP, NDI HX2, NDI HX3, RTMP, RTMPS, RTSP, SRT, VISCA
Ports: 3G-SDI - BNC, Audio line in - 3.5 mm jack, HDMI output, LAN/power - RJ-45, Serial RS-232/RS-422 input - RJ-45, Serial RS-232/RS-422 output - RJ-45, USB 3.0 - 9 pin USB Type B
Host Interface: USB 3.0
Technical Information
Angular Field of View (D, Max, Degree): 67.3
Angular Field of View (H, Max, Degree): 58.7
Angular Field of View (V, Max, Degree): 33
Focus Modes: Automatic, Manual
Video Signals: 3G-SDI, HDMI, USB
Max Focal Length: 94 millimetre
Optical Zoom: 20
Control Interface: RS-232, RS-422
Camera Type: Conference camera
Digital Zoom: 12
Max Panning Speed (degree/sec): 120
Max Tilting Speed (degree/sec): 80
Tilt: -30 to +90
Panning Range (degree): -170 to +170
Min Focus Distance: 19.7 inch
Minimum Illumination: 1 lux - 30 fps - F1.6 - 50 IRE
Total Pixels: 2,000,000 pixels
Video Modes: 1080/25p, 1080/30p, 1080/50p, 1080/60p, 720/30p, 720/50p, 720/60p
Image Sensor Size: 1/2.8"
Image Sensor Type: CMOS
Lens Aperture: F/1.6-2.8
Min Focal Length: 4.9 millimetre
Sensor Size (metric): 9.1 mm (1/2.8")
Digital Video Capture Resolution: 1280 x 720, 1920 x 1080
Max Frame Rate: 60 frames per second
Shutter Speed (Max): 1/10000 second (time unit)
Shutter Speed (Min): 1/25 second (time unit)
Video Formats: H.264, MJPEG
Video Input: Color
Audio Support: Yes
Audio Formats: AAC, PCM
Touchscreen: No
Max Video Resolution: 1920 x 1080
Physical Characteristics
Camera Mechanical Design: Pan / tilt / zoom
Dimensions and Weight
Height: 7.3 inch
Width: 7.5 inch
Depth: 5.4 inch
Weight: 3.31 lbs
Certifications and Listing
Compliant Standards: IEEE 802.3af, NDAA
TAA Compliant: Yes
Not sure this camera fits your setup? Send us the model of your NVR, VMS or current cameras and how you plan to mount and power it, and the DatorPro team will help you confirm compatibility before you order.
