Product Information
Luxul's SW-505-24P-R is a managed Layer 2/3 switch with 24 Gigabit PoE+ ports at up to 30 W and combo RJ-45/SFP uplinks, all on the rear for clean AV rack installs. It has a 250 W PoE budget, PoE self-healing, Dante and AES67 audio support and is TAA compliant.
Key Features
- 24 x 10/100/1000 RJ-45 PoE+ ports, 30 W
- Combo Gigabit RJ-45/SFP uplinks
- 250 W PoE budget
- Rear facing ports
- Dante and AES67, PoE self-healing
- Rack ears and rubber feet included
Product Information
Brand: Luxul
Manufacturer: shure inc
Product Line: Luxul
Model: SW-505-24P-R
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Black
Country: United States
Network and Communication
Advanced Switching: Layer 3
Switching Type: Gigabit Ethernet
Manageable: Yes
Routing Protocol: IGMP, IGMPv2, IGMPv3, MSTP, RSTP, STP
Performance: Forwarding rate (64‑byte packets): 38.69 Mpps, Switching capacity: 52 Gbps
Capacity: VLAN IDs: 4095
MAC Address Table Size: 8K entries
Jumbo Frame Support: 9216 bytes
Features: ACL support, AES67 audio network, Dante audio network, IGMP snooping, Layer 2 switching, PoE self-healing, ProWatch, QoS, VLAN trunking
Connectivity
Ports: 26
Port Quantity: 24
Port Type: 10/100/1000 (PoE+)
Ports (2nd) Quantity: 2
Ports Type (2nd): Combo Gigabit SFP/RJ-45
Interface Provided: 24 x 10/100/1000 Base-T (PoE+) RJ-45 30 Watt, 4 x Gigabit LAN RJ-45/SFP combo
Power Over Ethernet (PoE): PoE+
Power
Device Type: Internal power supply
Required Voltage: AC 100-240 volt
Frequency: 50 - 60 hertz
Power Consumption Operational: 152 watt
PoE Budget: 250 watt
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): Desktop, Rack-mountable
Height (Rack Units): 1
Status Indicators: Link/activity, PoE, System
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 17.4 inch
Depth: 8.3 inch
Weight: 6.61 lbs
Included Items
Included Accessories: 4 rubber feet, Rack mounting ears
Cables: 1 x power cable (US)
Certifications and Listing
Compliant Standards: CB, cUL, EMC, FCC, IC, LVD, NDAA, RCM, RoHS, UKCA, UL, VCCI
Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
TAA Compliant: Yes
Warranty
Limited Warranty: 3 Year
Service & Support Details: Limited warranty - 3 years
Service Activation: No
