Product Information
The Mean Well SDR-480-48 is a 480 W fanless DIN rail power supply with 48 to 55 V DC output at up to 10 A, active PFC (0.94) and 94 percent efficiency. It accepts 90 to 264 V AC or 127 to 370 V DC and has constant current limiting, LED indicators and protection against overload, short circuit, over voltage and overheating. It fits TS-35/7.5 or 15 DIN rails.
Key Features
- 480 W DIN rail PSU
- 48 to 55 V DC output
- Active PFC, 94% efficient
- Fanless design
- Full fault protection
- TS-35 DIN rail
Product Information
Brand: Mean Well
Manufacturer: IMC Networks
Product Line: Mean Well SDR-480 series
Model: SDR-480-48
Product Type: Power Supply
Subcategory: Power supplies
Packaged Quantity: 1
Color Category: Blue, Gray
Power
Power Factor (PF): 0.94
Power Factor Correction: Active Power Factor Correction (PFC)
Input Voltage Range: AC 90 - 264 / DC 127 - 370 V
Required Voltage: AC 115/230 volt
Frequency: 47 - 63 hertz
Power Device Features: Constant current limiting circuit, Fanless, LED indicators, Overheat protection, Overload protection, Overvoltage protection, Short-circuit protection
Power Provided: 480 watt
Form Factor (Power Device): DIN rail mountable
Power Supply Compatibility: Power equipment
Max Input Current: 10 ampere
Voltage Provided Margin: ± 1%
Efficiency: 94%
Provided Voltage: DC 48 - 55 volt
Technical Information
Min Operating Temperature: -13 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Operating Humidity: 20 - 95% (non-condensing)
MTBF: 112.900 Hours
Dimensions and Weight
Height: 4.9 inch
Width: 3.4 inch
Depth: 5.1 inch
Certifications and Listing
Compliant Standards: CB, cULus, EN 60950-1, EN 61000-3-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-2, EN 61204-3, EN55022, EN55024, IEC 60068-2-6, IEC 61000-4-11, MIL-HDBK-217F, TUV, UL 508
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Limited Warranty: 3 Year
Service & Support Details: Limited warranty - 3 years
