Product Information
The MSI PRO X870E-P WIFI is an ATX board for AMD Ryzen 9000, 8000 and 7000 processors on Socket AM5. It uses a 14+2+1 Duet Rail power design with dual 8-pin CPU connectors on an 8-layer PCB, supports up to 256 GB of DDR5 and adds Wi-Fi 7 with Bluetooth 5.4. PCIe 5.0, 4.0 and 3.0 slots give room to expand.
Key Features
- AMD X870E chipset, Socket AM5, ATX
- 4 x DDR5, up to 256 GB, up to 8200 MHz
- Wi-Fi 7, Bluetooth 5.4, Gigabit LAN
- 3 x PCIe x16 and 1 x PCIe x1 slots, PCIe 5.0 support
- 14+2+1 power design, dual 8-pin CPU power
- RAID 0/1/5/10, 7.1 channel audio
Product Information
Brand: MSI
Manufacturer: MSI
Series: PRO
Model: PRO X870E-P WIFI
Product Type: Gaming Desktop Motherboard
Color Category: Black, Silver, White
Network and Communication
Wireless LAN #2: Yes
Wireless LAN: IEEE 802.11 a/b/g/n/ac/ax/be
Wireless LAN: Yes
Bluetooth Standard: Bluetooth 5.4
Connectivity
Bluetooth: Yes
Gigabit Ethernet: Yes
PCI Express Slots: 4
PCI Express Standard: PCI Express 3.0, PCI Express 4.0, PCI Express 5.0
PCI Express x16 Slots: 3
PCI Express x1 Slots: 1
Audio Channels: 7.1
Memory and Processor
Processor Supported: Ryzen 7, Ryzen 9
Memory Form Factor: DIMM, UDIMM
RAID Supported: Yes
Onboard Video: CPU Dependent Video
Processor Socket: Socket AM5
Supported Memory Speed: 5600 megahertz, 6000 megahertz, 6400 megahertz, 8200 megahertz
Memory Slots: 4
Ram Capacity: 256 GB
Chipset Manufacturer: AMD
Chipset Model: X870E
RAID Levels: 0, 1, 10, 5
Memory Technology: DDR5 SDRAM
Total Processor Supported: 1
Physical Characteristics
Form Factor: ATX
Dimensions and Weight
Width: 12 inch
Depth: 9.6 inch
