Product Information
The NetAlly LINKSOLUTIONS-KT-4K kit pairs the LinkRunner AT 4000 network tester with two LinkSprinter network testers and their holsters, plus a LinkRunner AT holster. The LinkRunner AT 4000 tests copper and fiber links for connectivity, ping, wiremap and UPoE, and supports IEEE 802.3ab, af, at and bt. It has a 5 inch 720 x 1280 color touchscreen, 8 GB flash, RJ-45, SFP, USB-C and USB-A ports and a lithium ion battery for up to 9 hours. An RJ-45 coupler and 1 year of AllyCare support are included.
Key Features
- LinkRunner AT 4000
- 2 LinkSprinter testers
- Copper and fiber links
- Ping, wiremap, UPoE
- 5 inch touchscreen
- 1 year AllyCare support
Product Information
Tests, Tools and Measurements: Network connectivity, Ping, UPoE, Wiremap
Media: Copper, Fiber
Brand: NetAlly
Manufacturer: NetAlly
Product Line: NetAlly LinkRunner
Model: AT 4000
Product Type: Network tester
Packaged Quantity: 1
Network and Communication
Features #2: Touchscreen
Features: Build-in 8GB flash, Status LED, USB connectivity
Features: Touchscreen
Bundled Services: 1 year AllyCare support
Connectivity
Connectors: 24 pin USB type C, RJ-45, SFP, USB type A
Power
Battery Chemistry: Lithium ion
Battery Voltage: 3.63 volt
Output Voltage: 15 V
Battery Run Time (Up To): 9 Hours
Input Voltage: 100-240 V
Technical Information
Color Support: Color
Display Diagonal Size: 5 inch
Display Diagonal Size (metric): 12.7 centimetre
Display Resolution: 720 x 1280 pixels
Display Screen: LCD
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 113 degree Fahrenheit
Operating Humidity: 0 - 90% RH (non-condensing)
Min Storage Temperature: -4 degree Fahrenheit
Max Storage Temperature: 140 degree Fahrenheit
Dimensions and Weight
Height: 7.7 inch
Width: 4 inch
Depth: 1.7 inch
Weight: 16.93 ounce
Included Items
Included Accessories: 2 LinkSprinter holsters, 2 LinkSprinter network testers, LinkRunner AT holster
Cables: 1 x RJ-45 coupler
Certifications and Listing
Compliant Standards: CISPR 11 Group 1 Class A, IEC 61010-1:2010, IEC 61326-1, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z
