Product Information
Netgear's AV Line M4250-10G2F-PoE+ (GSM4212P) is a managed Layer 3 switch with ten Gigabit ports, eight of them PoE+, and two Gigabit SFP ports. It has a 125 W PoE budget and 24 Gbps of switching capacity, side to side airflow and mounting brackets in the box.
Key Features
- 10 x Gigabit RJ-45 ports, 8 with PoE+
- 2 x Gigabit SFP ports
- 125 W PoE budget
- 24 Gbps switching
- Layer 3 managed, AV over IP
- Mounting brackets included
Product Information
Brand: NETGEAR
Manufacturer: NETGEAR
Product Line: NETGEAR AV Line
Model: M4250-10G2F-PoE+
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Black
Network and Communication
Advanced Switching: Layer 3
Switching Type: Gigabit Ethernet
Manageable: Yes
Remote Management: CLI, HTTPS, RADIUS, RMON 1, RMON 2, RMON 9, SNMP, SSH, TACACS+, Telnet
Routing Protocol: IGMP, IGMPv2, IGMPv3, MLDv2, PIM-DM, PIM-SM, PIM-SSM, RIP, Static IPv4 routing, Static IPv6 routing
Performance: Firewall throughput (64-byte packet size): 17.86 Mpps, Latency (1 Gbps): < 2.27 µs, Switching capacity: 24 Gbps
Capacity: ARP entries: 4000, IGMP multicast groups: 2000, Jumbo frame size: up to 12000, MSTP instances: 16, Multicast entries (IPv4): 512, Multicast entries (IPv6): 128, PVST instances: 32, VLANs supported: 4093
MAC Address Table Size: 16K entries
Features: 16MB packet buffer, Authentication, Authorization and Accounting (AAA), Bridge protocol data unit (BPDU), DHCP relay, DHCP server, DHCP snooping, DoS attack prevention, Dynamic ARP Inspection (DAI), Dynamic VLAN Support (GVRP), GARP Multicast Registration Protocol (GMRP), IP source guard, Link Aggregation Control Protocol (LACP), Link Aggregation Group (LAG), LLDP-MED, Multiple VLAN Registration Protocol (MVRP), Policy based routing, Private VLAN, Protocol Independent Multicast (PIM), Quality of Service (QoS), Rapid Reconfiguration of Spanning Tree (RSTP), Remote Switch Port Analyzer (RSPAN), sFlow, Spanning Tree Protocol (STP) support, Spanning-tree Root Guard (STRG), VLAN support
Connectivity
Ports: 12
Port Quantity: 10
Port Type: 10/100/1000 (8 PoE+)
Ports (2nd) Quantity: 2
Ports Type (2nd): Gigabit SFP
Interface Provided: 1 x console (USB) Type C, 1 x console RJ-45, 1 x management (Gigabit LAN) RJ-45, 1 x USB Type A, 10 x 10/100/1000 Base-T RJ-45 8 ports (PoE+), 2 x 1000Base-X SFP
Power Over Ethernet (PoE): PoE+
Power
Device Type: Internal power supply
Power Consumption Operational: 17.32 watt
PoE Budget: 125 watt
Power Supplies Installed: 1
Memory and Processor
Processor Brand: ARM
Processor Number: A9
Clock Speed: 1.25 GHZ
RAM Installed: 2 GB
Flash Memory Installed: 256 megabyte
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Height (Rack Units): 1
Airflow Direction: Side to side airflow
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 17.3 inch
Depth: 7.9 inch
Weight: 6.28 lbs
Included Items
Included Accessories: Mounting brackets
Cables: Console cable, USB-C to USB-A cable
Certifications and Listing
Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.1as, IEEE 802.1AX, IEEE 802.1Qat, IEEE 802.1Qav, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3az
Compliant Standards: AN/NZS 60950.1:2015, ANSI C63.4:2014, AS/NZS CISPR32:2013 Class A, CCC, CISPR 32:2012, CNS 13438 Class A, CNS 14336-1, EN 55024:2010, EN 55032:2012+AC:2013 Class A, EN 60950-1:2006+A1:2010+A11:2009+A2:2013+A12:2011, EN 61000-3-2:2014 Class A, EN 61000-3-3:2013, FCC CFR47 Part 15 B Class A, GB 4943.1-2011, GB/T9254-2008 Class A, ICES-003:2016 issue 6 Class A, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, IEC60950/EN60950, IEEE 1588, VCCI-CISPR 32:2016 Class A, YD/T993-1998
ENERGY STAR Certified: No
