Product Information
Omada's SM311LM is a multimode 1000Base-SX SFP module for short reach Gigabit fiber links. It is MSA compliant and listed for TP-Link T3700, T2700, T2600, T2500, T1700, T1600 and T1500 series switches and the MC220L media converter. This is a transceiver, not a switch.
Key Features
- 1000Base-SX SFP transceiver
- Multimode fiber
- Hot swappable, MSA compliant
- For TP-Link/Omada switches and MC220L
Product Information
Brand: Omada
Manufacturer: TP-LINK Technologies Co., Ltd
Model: SM311LM
Product Type: SFP (mini-GBIC)
Usage: Data Networking, Optical Network
Compatibility: MSA CompliantTP-LINK|Switches:| T3700 series, T2700 series, T2600 series, T2500 series, T1700 series, T1600 series, T1500 series, 2/3/5 series,Media Converter:| MC220L
Country of Origin: China
Network and Communication
Data Link Protocols: Gigabit Ethernet
Network Technology: 1000Base-SX
Max Data Transfer Rate: 1.25 Gbit/s
Max Distance Supported: 0.55 kilometre
Fiber Mode Supported: Multi-mode
Connectivity
Ports: 1
Connector Type: LC/UPC
Interfaces & Port Details: 1 x LC/UPC 1000Base-SX Network
Technical Information
Min Operating Temperature: 32
Max Operating Temperature: 158
Physical Characteristics
Form Factor: Hot-swappable
Dimensions and Weight
Height: 0.5 inch
Width: 2.2 inch
Depth: 0.5 inch
Not sure this fits your network? Send us your current switch, router or chassis model and the DatorPro team will confirm compatibility before you order.
