Product Information
The Opengear CM8008 is a compact 8 port console manager for secure out-of-band access at sites with few serial devices or tight rack space, managed alongside Opengear Lighthouse. It has eight RS-232 RJ-45 ports, two gigabit RJ-45/SFP combo ports, two USB 3.0 and a USB-C console. A 1.6 GHz ARM A53 with 4 GB LPDDR4 and 32 GB flash adds TPM 2.0, Smart OOB, IP firewall policy, IPsec and OpenVPN, with AD, RADIUS and TACACS+ login. It fits 1U with the included rack kit and uses an external 110 to 240 V AC adapter.
Key Features
- 8 RS-232 RJ-45 ports
- 2 x GbE RJ-45/SFP combo
- TPM 2.0, Smart OOB
- IPsec and OpenVPN
- AD, RADIUS, TACACS+
- 1U rack kit included
Product Information
Brand: Opengear
Manufacturer: OPENGEAR
Product Line: Opengear
Model: CM8008
Product Type: Console server
Packaged Quantity: 1
Color Category: Black, Red
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232
Network Standard: IPSec, OpenVPN
Remote Management: SNMP
Authentication Method: Active Directory, RADIUS, TACACS+
Features: Firewall protection, IP-based Firewall Policy, Smart Out-of-Band, Trusted Platform Module 2.0 (TPM 2.0), Web-based UI
Connectivity
Ports: 8
Interface Provided: 1 x console - USB-C, 2 x Ethernet 1000 - RJ-45/SFP (mini-GBIC), 2 x USB 3.0 - Type A, 8 x RS-232 - RJ-45
Power
Device Type: External power adapter
Required Voltage: AC 110-240 volt
Memory and Processor
Processor Brand: ARM
Processor Number: A53
Processors Installed: 1
Clock Speed: 1.6 GHZ
RAM Installed: 4 GB
Memory Technology: LPDDR4 SDRAM
Flash Memory Installed: 32 GB
Total Processor Supported: 1
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 1
Dimensions and Weight
Height: 1.7 inch
Width: 8.7 inch
Depth: 7 inch
Weight: 2.76 lbs
Included Items
Included Accessories: Rack mount kit
Certifications and Listing
Compliant Standards: AS/NZS CISPR22:2009+A1:2010, C-Tick, CISPR 22:2008, CISPR 24:2010, EN 55022:2010, EN 55024:2010, EN 61000-3-2:2006+A2:2009, EN 61000-3-3:2008, EN 61000-4-11:2004, EN 61000-4-2:2009, EN 61000-4-3:2006+A2:2010, EN 61000-4-4:2004+A1:2010, RoHS
Not sure this console or device server fits your setup? Send us your equipment models, port counts and connection types, and the DatorPro team will confirm compatibility before you order.
