Product Information
The Opengear CM8132 is a 32 port console manager built for enterprise networks and data centers. Its thirty-two RS-232 RJ-45 ports use straight through cabling to Cisco style consoles at up to 230.4 Kbps, with two gigabit RJ-45 ports, two USB 3.0 and an RJ-45 console. A Marvell 88F6820 at 1.6 GHz with 2 GB DDR4 and 32 GB flash adds TPM 2.0 security and can host containerized apps and automation tools. It supports Smart Out-of-Band, IPsec VPN, firewall, AAA and AD, LDAP, RADIUS and TACACS+. It is passively cooled with dual redundant power supplies in 1U, and comes with rack ears, screws, a DB-9 to RJ-45 adapter and a 6 ft patch cable.
Key Features
- 32 RS-232 RJ-45 ports
- 2 x gigabit Ethernet
- TPM 2.0, Smart OOB
- Hosts containerized apps
- Dual redundant PSU
- 1U, rack kit included
Product Information
Brand: Opengear
Manufacturer: OPENGEAR
Product Line: Opengear
Model: CM8132
Product Type: Console server
Packaged Quantity: 1
Color Category: Black, Red
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232
Network Standard: IPSec, IPv6
Remote Management: HTTP, IPv6, SNMP, SSH
Authentication Method: Active Directory, LDAP, RADIUS, Secure Shell (SSH), TACACS+
Data Transfer Rate: 230.4 Kbps
Features: Authentication, Authorization and Accounting (AAA), ESD Protector, Firewall protection, Management Information Base (MIB), Passive cooling, Smart Out-of-Band, Trusted Platform Module 2.0 (TPM 2.0), VPN support
Connectivity
Ports: 32
Interface Provided: 1 x console - RJ-45, 2 x 1000Base-T - RJ-45, 2 x USB 3.0 - Type A, 32 x RS-232 - RJ-45
Power
Device Type: Internal power supply
Power Supplies Installed: 2
Power Supplies Supported: 2
Redundant Power Supply: Yes
Memory and Processor
Processor Brand: Marvell
Processor Number: 88F6820
Processors Installed: 1
Clock Speed: 1.6 GHZ
RAM Installed: 2 GB
Memory Technology: DDR4 SDRAM
Flash Memory Installed: 32 GB
Total Processor Supported: 1
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 1
Dimensions and Weight
Height: 1.7 inch
Width: 17.3 inch
Depth: 9.3 inch
Weight: 9.92 lbs
Included Items
Included Accessories: 2 rack mounting ears, 4 x screws, Nuts, Rack mount kit
Cables: 1 x DB-9 to RJ-45 adapter, 1 x patch cable - 6 ft
Certifications and Listing
Compliant Standards: AS/NZS CISPR 32:2015, CISPR 32:2016, CNS13438:2006, EN 55032:2017, EN 55035:2017, EN 61000-3-2:2019, EN 61000-3-3:2013, EN 61000-4-11:2004, EN 61000-4-2:2009, EN 61000-4-3:2006+A1:2008+A2:2010, EN 61000-4-4:2012, FCC Part 15 B Class A, ICES-003 issue 7, IEC 61000-3-2:2018, IEC 61000-3-3:2013, IEC 61000-4-11:2004, IEC 61000-4-2:2008, IEC 61000-4-3:2006+A1:2007+A2:2010, IEC 61000-4-4:2012, IEC 61000-4-8:2009, IEC 62368, RoHS, VCCI 32
Not sure this console or device server fits your setup? Send us your equipment models, port counts and connection types, and the DatorPro team will confirm compatibility before you order.
