Product Information
The Perle TC Extender carries Ethernet transparently up to 20 km over a single twisted pair (CAT5/6/7), coax or other existing copper wiring once used for alarm circuits, E1/T1, RS-232/422/485, CCTV or CATV. It supports auto-negotiation, auto MDI/MDI-X and IPv4/IPv6.
Specifications:
Brand: Perle
Manufacturer part number: 27024094
Cable type: Network extender
Data rate: 30 MBps
Features: Auto-negotiation, Auto-uplink (auto MDI/MDI-X), IPv4 support, IPv6 support
Height: 3.9 inch
Width: 1.4 inch
Weight: 9.12 ounce
Color: Gray
Operating temperature: -4°F to 140°F
Quantity in package: 1
Standards and compliance: ATEX Directive, China RoHS, cUL, cULus, EMC 2014/30/EU, EN 50121-4, EN 55011, EN 60068-2-27, EN 60068-2-6, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, IEC 60068-2-27, IEC 60068-2-6, IP20, REACH, RoHS, UL, UL 508, IEEE 802.3u, ITU-T G.991.2.bis
Reach: up to 20 km
