Product Information
Plugable's USBC-MSTH3 connects up to three high-resolution HDMI displays from one USB-C port using DisplayPort 2.1 Alt Mode and MST. It supports one 8K 60 Hz display, two 4K 144 Hz or three 4K 60 Hz, with HDR and HDCP. It is slim, bus powered and plug-and-play.
Key Features:
- USB-C input to 3x HDMI outputs
- 3x 4K 60 Hz / 2x 4K 144 Hz / 1x 8K 60 Hz
- DisplayPort 2.1 Alt Mode; MST; HDR; HDCP
- Bus powered; driverless
- Windows, ChromeOS and macOS
- Integrated USB-C cable
Specifications:
- Brand: Plugable
- Manufacturer Part Number: USBC-MSTH3
- Optical Drive Type: None
- Storage Controller Type: None
- Host Connection: USB-C
- Interface Provided: 3 x audio / video HDMI
- Video Interfaces: 3 x HDMI
- Supported Operating Systems: Apple MacOS, Google Chrome OS, Windows
- Feature Set: Bus Powered, HDR Support, MST (multi-stream transport)
- Max Resolution Details: 4K 144 Hz (Dual Display), 4K 60 Hz (Triple Display), 8K 60 Hz (Single Display)
- Product Category: Docking Station
- Cables: 1 x USB-C cable integrated
- Depth: 1.4 in
- Standards & Compliance: DisplayPort 1.4, DisplayPort 2.1, HDCP, Plug and Play
- Listed Dimensions: Height 0.4 in, Width 3.8 in
- Weight: 1.98 oz
