Product Information
The PNY GeForce RTX 5090 is a Blackwell based graphics card with 32 GB of GDDR7 memory for top end gaming, AI and creative work. It boosts up to 2.53 GHz, uses PCI Express 5.0 x16 and is cooled by a triple fan design. This is a graphics card listed in the CPU category and it comes with a 3 year limited warranty.
Key Features
- GeForce RTX 5090 with 32 GB GDDR7
- 2.02 GHz GPU clock, up to 2.53 GHz boost
- 3 DisplayPort and 1 HDMI, up to 4 monitors at up to 7680 x 4320
- PCI Express 5.0 x16, DLSS 4 and Reflex 2
- 1000 W power supply recommended, quad-slot, 12.9 inches long
- Limited warranty of 3 years listed for this card
Product Information
Platform Supported: Linux, PC
Brand: PNY
Manufacturer: PNY Technologies
Product Type: Graphic Card
Network and Communication
Features: Triple-fan Cooler
Connectivity
DisplayPort: Yes
DisplayPort Outputs: 3
HDMI Outputs: 1
Host Interface: PCI Express 5.0 x16
HDMI: Yes
Power
Power Connector: 1x 16-pin, 4x 8-pin
Power Supply Wattage: 1000 watt
Memory and Processor
Chipset Series: RTX
Chipset Line: GeForce
GPU Clock: 2.02 GHZ
Boost Clock Speed: 2.53 GHZ
AI-Powered: Yes
Chipset Manufacturer: NVIDIA
Chipset Model: RTX 5090
RAM Installed: 32 GB
Memory Technology: GDDR7
Technical Information
Monitors Supported: 4
Maximum Digital Display Resolution: 7680 x 4320
Physical Characteristics
Slot Space Required: Quad
Card Height: Full-height
Form Factor: Plug-in Card
Dimensions and Weight
Height: 2.8 inch
Width: 5.4 inch
Length: 12.9 inch
Warranty
Limited Warranty: 3 Year
