Product Information
This 3 meter (9.8 ft) Proline duplex patch cable has angled LC (male) connectors on both ends, which helps keep cable runs tidy where space at the ports is tight. It uses OS2 9/125 single mode fiber, the standard single mode type defined in ISO/IEC 11801, usually run at 1310 nm and 1550 nm with a maximum attenuation of 1 dB/km.
Two fiber strands pair naturally with transceivers that send and receive at the same time. The yellow OFNR (optical fiber nonconductive riser) jacket is made for indoor runs, including vertical risers.
General
Brand: Proline
Part number: PRO-ALC-ALC-3M9SMF
Cable type: Patch cable
Package quantity: 1
Cable and Fiber
Length: 3 m (9.8 ft)
Fiber: OS2 single mode, 9/125 µm
Cable mode: Duplex
Cable configuration: Crossover
Jacket: OFNR (riser rated)
Shielding: None
Color: Yellow
Features: Angled Physical Contact (APC), Bend Insensitive, Fire Resistant, Stranded
Connectors
Connectors: Angled LC (male) to angled LC (male)
Physical and Environmental
Width: 0.3 inch
Height: 0.1 inch
Weight: 0.20 lb
Compatibility
Supported devices: Network Device
Standards compatibility: Compatible OEM: Industry Standard
Typical use: Business, Data Center, Data Transmission, Indoor, Industrial, Office, Vertical Riser
Compliance and Warranty
TAA compliant: No
Country of origin: China
