Product Information
This 1 meter (3.3 ft) Proline trunk style cable carries 12 strands of os2 single mode 9/125 fiber between two female MPO connectors with angled (APC) polish. OS2 is the standard single mode fiber type defined in ISO/IEC 11801, usually run at 1310 nm and 1550 nm with a maximum attenuation of 1 dB/km.
The yellow jacket carries an OFNR riser rating, so the cable can be run vertically through building risers between floors where riser rated cabling is required. The connectors use a standard boot, and Proline builds these cables to TIA standards.
General
Brand: Proline
Part number: PRO-MPOMPO-1M9SMF
Cable type: Patch cable
Package quantity: 1
Cable and Fiber
Length: 1 m (3.3 ft)
Fiber: OS2 single mode, 9/125 µm
Fiber count: 12
Cable configuration: Crossover
Jacket: OFNR (riser rated)
Shielding: None
Color: Yellow
Features: Angled Physical Contact (APC), Bendable, Fire Resistant, Stranded
Connectors
Connectors: MPO/APC (female) to MPO/APC (female)
Polish: APC
Physical and Environmental
Width: 0.3 inch
Height: 0.1 inch
Weight: 0.10 lb
Compatibility
Supported devices: Network Device
Compliance and Warranty
TAA compliant: No
Country of origin: China
