Product Information
The Proxim Stratum X5 (SX5-1042A-US) is a 5 GHz point to point bridge radio, not a standalone antenna, with four internal 18 dBi antennas and four RP-SMA ports for external antennas. It uses 4x4:4 MU-MIMO, 1024 QAM and 20/40/80 MHz channels, with 1.58 Gbps throughput listed. Ports are one 10G SFP+, one 2.5 GbE PoE and one gigabit PoE. It offers ClearConnect, BlueConnect, a spectrum analyzer, VLAN and QinQ, QoS, SNMP v1 to v3, SSH, RADIUS and 128/256-bit AES. It draws about 25 W, survives 180 km/h winds and comes with a power injector, mounting and grounding kits, two M25 glands, port caps and a US power cable.
Key Features
- 5 GHz bridge, not an antenna
- 4x4 MU-MIMO, 18 dBi
- 10G SFP+, 2.5 GbE, 1 GbE
- Spectrum analyzer
- AES-256, SNMP, RADIUS
- Injector and mounts included
Product Information
Brand: Proxim
Manufacturer: Wincomm
Product Line: Proxim Stratum
Model: X5
Product Type: Wireless bridge
Device Type: Power injector
Packaged Quantity: 1
Color Category: Gray
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: 10 Gigabit Ethernet (optical), 2.5 Gigabit Ethernet, Gigabit Ethernet
Network Standard: IPv4, IPv6
Remote Management: SNMP 1, SNMP 2c, SNMP 3, SSH, Syslog, Telnet, TFTP, TLS
Routing Protocol: WORP
Authentication Method: RADIUS, Secure Shell v.2 (SSH2)
Encryption: 128-bit AES, 256-bit AES, TLS 1.3
Data Transfer Rate: 10 GBps
Line Coding Format: 1024 QAM, BPSK, OFDM
Spread Spectrum Method: OFDM
Network Device: Channel width: 20 / 40 / 80 MHz, Throughput: 1.58 Gbps
Antennas: 4
Antenna Form Factor: Internal
Antenna Gain Level: 18 DBi
Frequency Band: 5 GHZ
Features: 180 km/h wind survival, 4x4:4 MU-MIMO technology, Auto-uplink (auto MDI/MDI-X), MAC address filtering, Point-to-Point (PtP) link mode, Proxim BlueConnect, Proxim ClearConnect, QinQ VLAN, Quality of Service (QoS), SNTP support, Spectrum analyzer, VLAN support
Connectivity
Interface Provided: 1 x 10 Gigabit Ethernet - SFP+, 1 x 1000Base-T (PoE) - RJ-45, 1 x 2.5 GBase-T (PoE) - RJ-45, 4 x antenna - RP-SMA
Power
Power Consumption Operational: 25 watt
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 140 degree Fahrenheit
Operating Humidity: 100%
MTBF: 450,000 Hours
Physical Characteristics
Form Factor: External
Dimensions and Weight
Height: 14.6 inch
Width: 14.6 inch
Depth: 3.8 inch
Weight: 6.61 lbs
Included Items
Included Accessories: 2 x cable glands M25, Grounding kit, Mounting kit, Port protective caps, Power cable (US)
Certifications and Listing
Compliant Standards #2: IEEE 802.1Q, IEEE 802.3at, IEEE 802.3bt
Compliant Standards: BS EN IEC 62368-1:2020 + A11:2020, CSA C22.2 No. 62368-1:19, FCC CFR47 Part 15 B Class A, FCC Part 15 Subpart C 15.247, FCC Part 15.205, FCC Part 15.207, FCC Part 15.209, FCC Part 15.247, FCC Subpart E 15.407, IEC 62368-1:2018, IP67, UL 62368-1:2019
Compliant Standards: IEEE 802.1Q, IEEE 802.3at, IEEE 802.3bt
Warranty
Limited Warranty: 2 Year
Service & Support Details: Limited warranty - 2 years
Service Activation: No
