Product Information
QNAP's QSW-M2130P-2C2S26T is a Layer 2 web managed rack switch with 24 2.5G RJ-45 ports with PoE++ and six 10G ports: two RJ-45, two SFP+ and two combo RJ-45/SFP+. It has a 375 W PoE budget and 240 Gbps of switching capacity, with VLAN, QoS, ACL and LACP.
Key Features
- 24 x 2.5G RJ-45 PoE++ ports
- 2 x 10G RJ-45 ports
- 2 x 10G SFP+ ports
- 2 x combo 10G RJ-45/SFP+ ports
- 375 W PoE budget, 240 Gbps
- Web managed, 1 power supply, rack mount
Product Information
Brand: QNAP
Manufacturer: QNAP
Product Line: QNAP
Model: QSW-M2130P-2C2S26T
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Black
Country: United States
Network and Communication
Switching Type: 10 Gigabit Ethernet / 2.5 Gigabit Ethernet
Manageable: Yes
Remote Management: RSTP
Routing Protocol: IGMP
Performance: Non-blocking switching throughput: 120 Gbps, Switching capacity: 240 Gbps
MAC Address Table Size: 32K entries
Jumbo Frame Support: 12KB
Features: ACL support, Energy-Efficient Ethernet (EEE), LACP support, Layer 2 switching, Quality of Service (QoS), Reset button, VLAN support, Web-based management
Connectivity
Ports: 30
Port Quantity: 2
Port Type: 10 Gigabit SFP+
Ports (2nd) Quantity: 2
Ports Type (2nd): Combo 10 Gigabit SFP+/RJ-45
Ports (3rd) Quantity: 2
Ports (4th) Quantity: 24
Ports (4th) Type: 2.5GBase-T
Interface Provided: 1 x console RJ-45, 2 x 10Gbit LAN RJ-45, 2 x 10Gbit LAN RJ-45/SFP+, 2 x 10Gbit LAN SFP+, 24 x 2.5Gbit LAN RJ-45
Power Over Ethernet (PoE): PoE++
QSFP Slots: 10Gb Ethernet
Power
Device Type: Internal power supply
Required Voltage: AC 100-240 volt
Frequency: 50/60 hertz
Power Consumption Operational: 455 watt
PoE Budget: 375 watt
Power Supplies Installed: 1
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 122 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Built-in Devices: 3 x fans
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 17.3 inch
Depth: 8.1 inch
Weight: 7.8 lbs
Included Items
Included Accessories: Power cord
Certifications and Listing
Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3x, IEEE 802.3z
Compliant Standards: BSMI, FCC, ICES, LVD, RCM, UKCA, VCCI
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
