Product Information
The Raritan Dominion SX II DSX2-16M is a 16 port serial console server that gives secure IP access to network gear, servers, PDUs and telecom devices from anywhere. It has sixteen RJ-45 serial ports, two Ethernet ports, an internal RJ-11 modem, an RJ-45 console, a DVI-D local port, four USB and a mini USB. It supports up to 200 simultaneous connections, SSL encryption, SSH, LDAP, RADIUS and TACACS+ login, IPv4 and IPv6, and web, SNMP and Telnet management. It has dual power supplies drawing about 22 W, fits 1U and comes with a rack kit and rubber feet.
Key Features
- 16 RJ-45 serial ports
- Built-in modem, RJ-11
- Up to 200 connections
- Dual power supplies
- SSH, LDAP, RADIUS
- 1U, rack kit included
Product Information
Brand: Raritan
Manufacturer: Raritan
Product Line: Raritan Dominion SX
Model: DSX2-16M
Product Type: Console server
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, PPP, Serial
Network Standard: TCP/IP, UDP/IP
Remote Management: HTTP, HTTPS, SNMP, SSH, Telnet
Authentication Method: LDAP, PAP, RADIUS, Secure Shell (SSH), TACACS+
Encryption: SSL
Capacity: Simultaneous connections: 200
Features: IPv4 support, IPv6 support, Reset button
Connectivity
Ports: 16
Interface Provided: 1 x console - RJ-45, 1 x DVI-D, 1 x mini-USB, 1 x modem - RJ-11, 16 x serial - RJ-45, 2 x 100Base-TX - RJ-45, 4 x USB - Type A
Power
Device Type: Internal power supply
Frequency: 50/60 hertz
Power Consumption Operational: 22 watt
Power Supplies Installed: 2
Memory and Processor
Clock Speed: 1 GHZ
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 122 degree Fahrenheit
Operating Humidity: 20 - 85% (non-condensing)
Physical Characteristics
Form Factor: External
Height (Rack Units): 1
Status Indicators: Power, Status
Included Items
Included Accessories: 4 rubber feet, Rack mount kit
Certifications and Listing
Compliant Standards: cULus, FCC Part 15 A, UL
Warranty
Limited Warranty: 2 Year
Service & Support Details: Limited warranty - 2 years
Not sure this console or device server fits your setup? Send us your equipment models, port counts and connection types, and the DatorPro team will confirm compatibility before you order.
