Product Information
This Ruckus E1MG-LX-OM is a 1000Base-LX SFP optic for single-mode fiber with an LC connector, reaching up to 6.2 miles. It supports digital optical monitoring and is listed for Brocade ICX 6430, 6450, 7750 and VDX 67xx switches. This is a transceiver, not a switch.
Key Features
- 1000Base-LX SFP transceiver
- LC connector, single-mode fiber
- Up to 6.2 miles reach
- Digital optical monitoring (DOM)
- For Brocade ICX 6430/6450/7750, VDX 67xx
Product Information
Brand: Ruckus
Manufacturer: Ruckus Wireless
Product Line: Ruckus
Product Type: SFP (mini-GBIC) transceiver module
Compatibility Specs: Brocade ICX 6430-24, 6430-24P, 6430-48, 6430-48P, 6430-C12, 6450-24, 6450-24P, 6450-48, 6450-48P, 6450-C12-PD, 7750-26Q, 7750-48C, 7750-48F ¦ Brocade VDX 6710, 6720, 6730, 6740, 6740T, 6740T-1G
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Gigabit Ethernet
Cable Type: Ethernet 1000Base-LX
Data Transfer Rate: 1 GBps
Max Transfer Distance: 6.2 miles
Optical Wave Length: 1310 nm
Features: Digital Optical Monitoring (DOM) support
Connectivity
Interface Provided: 1 x Ethernet 1000Base-LX - LC single-mode female x 2
Compatible Slots Required: 1 x SFP (mini-GBIC)
Left Connector SD Type: LC single-mode
Physical Characteristics
Form Factor: Plug-In Module
Certifications and Listing
Compliant Standards: IEEE 802.3z
Compliant Standards: CSA C22.2 No. 60950-1-03, EN 60825-1, EN 60950-1, RoHS 5/6, RoHS 6/6, UL 60950-1
Not sure this fits your network? Send us your current switch, router or chassis model and the DatorPro team will confirm compatibility before you order.
